Model:MX2*D

Type:Multiplexer Card

Interface:Temperature/Current Input

Processing Capacity:Dual Channels

Signal Range:-200°C to +850°C for Temperature; 4 mA to 20 mA for Current

Sampling Rate:Up to 1 kHz

Power Supply:24 VDC

Communication Protocol:Modbus RTU, DeviceNet, CANopen

Operating Environment:Temperature: -20°C to +70°C, Humidity: 5% to 95% non-condensing

Dimensions:105 x 90 x 50 mm

Weight:0.2 kg

    Introducing the YOKOGAWA MX2*D Multiplexer Card, an essential component for any industrial control system aiming to enhance efficiency and accuracy in temperature measurement and control. This advanced card is specifically designed to manage and process data from two thermocouple or RTD input points simultaneously, ensuring precise readings across a wide range of operating temperatures.

    Featuring robust signal processing capabilities, the MX2*D supports various thermocouple types (Type K, J, E, T) and RTDs (Pt100), making it versatile for diverse industrial applications. With a sampling rate of up to 1 kHz, this card ensures real-time data acquisition, crucial for dynamic control processes.

    Equipped with dual Form C relay outputs, the MX2*D Multiplexer Card provides reliable switching for control signals, enabling seamless integration with various actuators and control devices. Its 24V DC power supply ensures compatibility with most industrial circuits, further enhancing its adaptability.

    Accurate to within ±0.1% FS ±2 digits, the YOKOGAWA MX2*D guarantees high precision measurements, critical for maintaining operational efficiency and quality control in manufacturing and process industries. The compact dimensions of 100mm x 90mm x 28mm make it easy to integrate into existing systems without compromising on space.

    Designed with durability and reliability in mind, the MX2*D Multiplexer Card by YOKOGAWA is engineered to withstand harsh industrial environments, ensuring continuous operation even under challenging conditions. It’s an indispensable upgrade for optimizing temperature control systems in various sectors, including chemical, petrochemical, and food processing industries.
