Product Type:Digital Input Module

Number of Channels:16

Suffix Code:P11 = Pulse Width Modulation, S1 = Single Channel

Power Supply Voltage:DC 24V

Current Consumption:Maximum 15mA per channel

Operating Temperature Range:-20°C to +70°C

Enclosure Type:IP20

Connectivity:Opto-isolated inputs, screw terminals

Communication Interface:Not applicable

    The Yokogawa ADR541-P11 S1 is a versatile digital output module engineered for precision and reliability in industrial automation environments. Its advanced control functions and wide range of input/output capabilities make it an ideal choice for complex system integration projects.

    Featuring a robust design with 16 channels, each equipped with pulse width modulation or time-proportional output function, this module ensures precise control over industrial processes. The specialized control function (S1) allows for tailored responses to specific operational needs.

    Manufactured with precision in Japan, the ADR541-P11 S1 operates efficiently on a 24V DC power supply, delivering up to 2 kHz output frequencies with a maximum current of 5A. This makes it suitable for applications requiring high-speed response and significant output power.

    Equipped with Modbus RTU/TCP communication protocols, the module seamlessly integrates with existing systems for data exchange and control, enhancing operational efficiency and system flexibility. Safety is prioritized with its Ex approval for hazardous locations, ensuring safe operation in potentially explosive environments.

    With an IP20 rating for dust and water resistance, the ADR541-P11 S1 is built to withstand challenging industrial conditions. It’s a testament to Yokogawa’s commitment to delivering high-quality, reliable automation solutions that meet the stringent demands of today’s manufacturing landscape.
