Input Current: 1.5A.
Output Current: 2A.
Operating Temperature Range: -40°C to 70°C, though some sources mention a range of -10°C to 70°C.
Storage Temperature Range: -40°C to 85°C.
Communication Interfaces: Supports Ethernet, RS-232, RS-485, and USB for seamless integration with other systems.
Memory Capacity: 32MB.
Dimensions and Weight: Dimensions vary slightly between versions, with one reported as 120mm x 80mm x 35mm, and another as 132mm x 105mm x 52mm. The latter version weighs 800g.
Functional Characteristics (功能特点):
High Reliability and Durability: Triconex 3503E is designed with industrial-grade components to ensure stable operation in harsh environments and demanding conditions. It boasts high endurance and resistance to interference, making it suitable for critical applications in industrial automation control systems.
Redundancy Design: Featuring dual processors and dual power inputs, the module provides system-level redundancy and fault tolerance. This minimizes the impact of system failures on operations, enhancing overall reliability and availability.
Rapid Response and High-Speed Processing: With fast response times and high-speed data processing capabilities, Triconex 3503E enables real-time monitoring and control of industrial processes, enabling swift actions in case of abnormalities to ensure system safety and stability.
Multiple Input/Output Channels and Interfaces: The module offers multiple digital and potentially analog input/output channels, supporting various communication protocols and interface standards such as Ethernet, analog I/O, digital I/O, etc. This versatility allows for seamless integration with a wide range of devices and systems.
Programmability: It is highly programmable, allowing users to implement various control logics and functions through programming and configuration. This flexibility enables customization based on specific application requirements.
Application Scenarios (应用场景):
Triconex 3503E is widely used in various industrial automation and process control applications. Its high reliability, fast response, and programmability make it an ideal choice for monitoring and controlling critical processes in sectors such as:
Power and Energy Industry: For monitoring and controlling power generation, transmission, and distribution systems.
Process Industries: Including chemical, petrochemical, and oil & gas industries, for monitoring and controlling complex processes involving fluids, gases, and solids.
Manufacturing: For automated production lines, where real-time monitoring and control of machinery and equipment are crucial.
Water and Wastewater Treatment: For monitoring and controlling water treatment processes, ensuring compliance with quality standards.
