Technical Specifications

• Number of Serial Channels: 8
• Interface Standards Supported: RS232, RS422
  • RS232: RxD, TxD, RTS, CTS, GND, DTR, DCD, RI
  • RS422: TxD+/-, RxD+/-, GND
• FIFO Size: 64 bytes for transmit, 64 bits for receive per channel
• Module Width: Single-width PMC module
• Bit Width: 32-bit
• Programmable FIFO Trigger Levels: Yes

Functional Characteristics

• High Precision Control: Capable of precise motor position control, providing high stability in motion performance.
• Fast Response: Quickly adjusts motor speed and position to adapt to varying operational demands.
• Multiple Control Modes: Supports position control, speed control, and torque control, catering to different application scenarios.
• Easy Integration: Features standard interfaces and communication protocols for seamless integration with other industrial devices and systems.
• High Reliability: Undergone rigorous quality control and durability testing, ensuring high reliability and stability in harsh industrial environments.
• Intelligent Protection Functions: Equipped with various intelligent protection functions such as overload protection, overheat protection, and voltage anomaly protection.

Application Scenarios

Tews TPMC866-11 is ideal for applications requiring precise positioning, speed control, and torque management in industrial automation. It can be found in:

• Manufacturing Lines: For automated assembly and production processes.
• Robotic Systems: To control the movements of industrial robots.
• CNC Machines: For precise machining and cutting operations.
• Automation Equipment: In various automation equipment that requires high-precision control.
