SIEMENS SIMATIC HMI TOUCH PANEL 6AV6542-0CC10-0AX0 – Operator Panel for Industrial Automation
The SIEMENS HMI Touch Panel 6AV6542-0CC10-0AX0 offers advanced human-machine interface capabilities, enabling seamless interaction between operators and industrial systems, thus optimizing production processes and enhancing operational efficiency.
Detailed content
Net Weight (kg):0.503
Packaging Dimension (WxDxH):15,40 x 18,70 x 5,60 cm
Display Size:10 inches
Display Technology:STN color
Configuration Memory:2 MB
Display Backlight:LED
Operating System Compatibility:SIMATIC S5, 505, S7, M7
Communication Interface:PROFIBUS DP 12 Mbaud
Approval:UL/CSA
Experience enhanced efficiency and streamlined operations with the SIEMENS 6AV6542-0CC10-0AX0 HMI Touch Panel. Designed with a 10.4″ STN color display, this operator panel provides clear visual feedback for your industrial processes.
With a 2 MB configuration memory, you can easily manage and customize your control logic using ProTool from Version V6.0 or later. This flexibility ensures compatibility across various Siemens automation systems, including SIMATIC S5, 505, S7, and M7.
Built to withstand harsh industrial environments, this touch panel operates within a wide temperature range of -20°C to +55°C and maintains functionality during storage in temperatures as low as -40°C and up to +70°C.
Featuring a robust DC power supply of 12-24V, the panel supports Profibus DP 12 Mbaud, RS422/485 interfaces, and Ethernet (RJ45) for seamless data exchange with other Siemens devices, ensuring a cohesive control system setup.
Equipped with a host USB type A port, the SIEMENS 6AV6542-0CC10-0AX0 enables convenient firmware updates and data transfers, streamlining maintenance and upgrade procedures without the need for specialized tools.
