Model Number:7SJ5115-4CA02-2BA0/JJ

Manufacturer:Siemens

Type:Control Module

Module Series:7SJ

Application Area:Industrial Automation

Operating Voltage:DC 24V

Output Current:Up to 1A

Relay Type:SPDT

Load Capacity:Up to 250V AC, 1A

Connection Method:Terminal Block

Protection Class:IP20

Operating Temperature:-10°C to +55°C

Storage Temperature:-20°C to +70°C

Dimensions (W x H x D):95mm x 40mm x 35mm

Weight:50g

    The Siemens 7SJ5115-4CA02-2BA0/JJ is a high-performance relay module designed to meet the stringent demands of industrial control applications. This module is characterized by its robust design, ensuring reliability and longevity in harsh environments.

    Featuring a wide operating voltage range of DC 24V, it supports various control circuits and can handle currents up to 16A at 125VAC or 10A at 24VDC. The fast switching speed of less than 2 milliseconds minimizes downtime and improves overall system efficiency.

    With an insulation resistance of ≥100MΩ, this module ensures isolation and safety in electrical systems. It is rated to operate within a temperature range of -25°C to +60°C and maintains functionality within humidity levels of 5% to 95% non-condensing, making it suitable for diverse industrial settings.

    Designed with precision in mind, the 7SJ5115-4CA02-2BA0/JJ offers accurate control over electrical circuits, facilitating complex operations and enhancing process control in industries such as manufacturing, automation, and power management.

    Its compact size and modular design allow for easy integration into existing control systems, simplifying installation and maintenance processes. This makes it an ideal choice for engineers and technicians seeking a reliable, efficient, and adaptable relay solution for their industrial control needs.
