SIEMENS 6ES7223-1PM22-0XA8 – 32DI DC24V/32DA Relay Input Output Module
The SIEMENS 6ES7223-1PM22-0XA8 is a versatile modular programmable logic controller (PLC) module designed for industrial automation applications, featuring 32 digital inputs (DI) with DC24V power supply and 32 relay outputs (DO). It’s optimized for efficient control and monitoring tasks in various manufacturing environments.
Detailed content
Number of Digital Inputs:32
Digital Input Voltage:DC24V
Number of Digital Outputs:32
Output Type:Relay
Operating Temperature Range:-25°C to +60°C
Power Consumption:≤ 15 W
Communication Interface:Built-in RS485
Connector Type:Spring-Loaded Terminal Block
Module Size:Compact (102 x 100 x 66 mm)
Certifications:CE, UL, CSA
The SIEMENS 6ES7223-1PM22-0XA8 is engineered for seamless integration into complex industrial systems, offering high reliability and precision in handling both input and output operations. Its compact design ensures minimal space occupation on the control panel.
Each digital input is equipped to detect and process signals from sensors and actuators, while the relay outputs provide robust control over actuators and other electrical devices. This module supports a wide range of applications, from simple machine control to intricate process automation.
The built-in communication interface facilitates easy connection to higher-level control systems or remote monitoring stations, enhancing operational efficiency and reducing setup time. The module’s ability to operate within a broad temperature and humidity range makes it suitable for diverse industrial settings.
With its advanced diagnostic capabilities, the 6ES7223-1PM22-0XA8 enables quick troubleshooting and maintenance, minimizing downtime and maximizing productivity. It is also certified to international safety standards, ensuring compliance and reliability in global applications.
Designed for longevity and durability, this PLC module is an essential component for modern industrial automation, providing a solid foundation for scalable and flexible control solutions.
