Siemens 6AV6545-0AG10-0AX0 Multi Panel Control Module
The Siemens Multi Panel – 6AV6545-0AG10-0AX0 is a high-performance, all-in-one solution designed for industrial control applications. It seamlessly integrates a wide range of functionality, including advanced process control, data acquisition, and human-machine interface (HMI) capabilities, making it suitable for various industrial environments and processes.
Detailed content
Operating System:SIMATIC HMI
Display Type:TFT
Display Size:7″
Color Depth:65536 Colors
Touch Operation:Key/Touch
Interface:PROFIBUS
Configurable Software:WinCC Basic V13/STEP 7 Basic V13
Software License:Free Open-Source
Dimensions:W x H x D (mm)
:190 x 140 x 38
Weight:Approx. 1.5 kg
Experience unparalleled control and monitoring capabilities with our Siemens 6AV6545-0AG10-0AX0 Multi Panel Control Module, engineered to elevate your industrial automation systems. Its 7-inch TFT display with 65,536 color depth ensures clear visibility under various lighting conditions, making it ideal for high-demand applications.
Our HMI module supports WinCC Basic V13 and STEP 7 Basic V13, providing a user-friendly interface for programming and system configuration. With Profibus DP communication, it seamlessly integrates into existing network infrastructures, ensuring efficient data exchange with other devices.
Built with durability and reliability in mind, this module features an AC/DC power supply that supports a wide range of power inputs, ensuring uninterrupted operation in diverse environments. It is rated IP20, protecting against dust and light splashes, suitable for industrial settings.
Compact yet powerful, the dimensions of 220x152x63 mm make it easy to integrate into tight spaces without compromising on functionality. Weighing approximately 1.3 kg, it is portable and manageable for installation and maintenance purposes.
In addition to its technical prowess, the Siemens 6AV6545-0AG10-0AX0 Multi Panel Control Module comes equipped with open-source software, provided free of charge. This feature enables customization and adaptation to specific needs, fostering innovation and cost-effectiveness in your manufacturing processes.
