Module Type:Transistor Output

Model Number:JW-232S

Input Voltage Range:12-24V DC

Output Voltage:24V DC

Maximum Load Current:1A

Operating Temperature:-20°C to +70°C

Relay Rating:500mA @ 24V DC

Isolation Voltage:2500V AC

Package Size:50mm x 50mm x 20mm

Weight:50g

    The SHARP JW-232S Transistor Output Module is engineered to deliver exceptional performance in control systems across various industries. With its robust design, it ensures reliable operation in diverse environmental conditions, making it an ideal choice for critical applications.

    Featuring a compact size and lightweight construction, this module is easily integrated into existing systems without compromising on functionality. Its high-speed switching capability allows for responsive control, enhancing system efficiency.

    Designed with precision in mind, the JW-232S supports a wide operating voltage range, ensuring compatibility with a broad spectrum of power sources. The module’s ability to handle up to 50mA current per channel provides flexibility in managing different load requirements.

    Adhering to strict quality standards, each JW-232S undergoes rigorous testing to ensure longevity and reliability over extended periods of use. Its operation within a temperature range from -20°C to +70°C and humidity range of 5% to 95% RH (non-condensing) guarantees consistent performance under varied environmental conditions.

    For ease of installation and maintenance, the module employs a pin header connector, facilitating quick assembly and disassembly processes. This feature, combined with its small footprint, optimizes space utilization in compact control panels or automation setups.
