Brand:Schneider

Model:SDC40

Module Type:Digital Controller Module

Operating Voltage:24 V DC

Current Rating:1 A

Input Channels:8

Output Channels:8

Communication Interface:Ethernet, Modbus TCP/IP

Operating Temperature Range:-20°C to +60°C

Storage Temperature Range:-40°C to +85°C

Protection Rating:IP20

Dimensions:140 mm x 90 mm x 63 mm (W x H x D)

Weight:0.5 kg

    The Schneider SDC40 Control Module is a high-performance control module designed for industrial automation applications. Its robust design ensures reliable operation in challenging environments. The module features an input voltage range of 12-24 VDC and an output voltage range of 12-24 VDC, making it versatile for different system requirements. With an operating temperature range from -25°C to 60°C, it can withstand harsh conditions. The module is protected by an IP30 rating, offering protection against dust ingress and contact with hazardous parts. At 100mm x 60mm x 35mm, the compact size makes it easy to integrate into existing systems without requiring much space. The module weighs only 0.2kg, making installation straightforward. Communication interfaces include RS485 and Ethernet, enabling seamless integration with other devices and systems. The Schneider SDC40 also includes relay outputs capable of handling up to 1A at 24VDC, providing reliable switching capabilities.
