Manufacturer:Rockwell Automation

Model:1794-IV16

Module Type:Flex I/O Analog Input Module

Number of Channels:16 Channels

Input Range:±10V or 0-20mA

Resolution:16-bit

Accuracy:±0.05% of reading ±1 LSB

Power Supply:24V DC

Mounting:DIN Rail

Operating Temperature Range:-40°C to +85°C

Environmental Protection Rating:IP20

    The Allen-Bradley 1794-IV16 is a robust and versatile analog input module designed for demanding industrial environments. With eight input channels capable of handling ±10V signals, this module provides high-resolution data acquisition suitable for a wide range of applications.

    The 1794-IV16 features a 12-bit resolution, enabling precise measurements that are crucial for accurate control and monitoring. Its sampling rate of up to 200 samples per second ensures timely data collection, making it ideal for real-time process control.

    This module operates on a 24V DC power supply, providing consistent performance even under fluctuating conditions. It is mounted easily on a DIN rail, offering a space-saving design that integrates seamlessly into existing control panels.

    Designed with durability in mind, the 1794-IV16 complies with stringent industry standards including CE, UL, and CSA certifications. This ensures reliability and safety in diverse operational settings.

    In summary, the Allen-Bradley 1794-IV16 is an essential component for any industrial automation system requiring precise and reliable analog data acquisition. Its advanced features and robust design make it a top choice for professionals in manufacturing, process control, and data logging applications.
