Technical Specifications

• Frame Size: 3023
• Operating Voltage: 230V AC
• Maximum Radial (FR) Load: 35 kg
• Number of Poles: 8
• Optical Encoder Line Count: 2000 P/R with commutation signal
• Resolution: 2000 P/R
• Speed Rating: 4500 RPM
• Enclosure Protection: IP43
• Dimensions: 140 x 80 x 80 mm (5.57 x 3.15 x 3.15 inches)
• Shaft Diameter: 16 mm (0.63 inches)
• Operating Temperature Range: 0 to 40 °C (32 to 104 °F)

Functional Characteristics

• Precise Control: The motor can accurately control position, speed, and acceleration, enhancing production efficiency and product quality.
• High Responsiveness: With fast response speed, it can complete position or speed changes in a short period of time.
• Programmability: It typically comes with programmable controllers allowing for parameter adjustment and control logic programming based on specific applications.
• Reliability: Made of high-quality materials and advanced manufacturing processes, it offers a long service life and stable performance.
• Low Inertia for Fast Acceleration: Equipped with high-energy magnets (neodymium).
• Maintenance Convenience: Designed for easy maintenance, with regular checks, cleaning, and maintenance ensuring long-term stable operation.

Application Scenarios

• Industrial Automation: Used to control movements on production lines, such as in assembly lines, packaging machinery, and other automation systems.
• CNC Machines: Widely used in controlling the precise movement of tools and worktables.
• Printing and Packaging: Provides high-precision position and speed control for fine printing and packaging processes.
• Medical Equipment: Utilized in medical imaging devices, surgical robots, and other medical equipment for precise motion control.
• Aerospace: Plays a crucial role in flight control systems of aircraft and spacecraft, ensuring stability and precise navigation.
• Robotics: Used extensively in various industrial and service robots for complex movements and operational tasks.
