Rated Voltage:20…35 V DC

Power Dissipation:1.8 W

Power Consumption:2.4 W

Connection:screw terminals

Mounting:on 35 mm DIN mounting rail acc. to EN 60715:2001

Mass:approx. 200 g

Dimensions:20 x 124 x 115 mm

Product Type:Temperature Converter

Extended Product Type:Universal Temperature Converter

Input Capability:Thermocouple, RTD, potentiometer or voltage

Output Capability:Current output 0/4 mA … 20 mA sink or source mode

Configurability:Configurable by PACTware

Fault Detection:Line fault (LFD) and sensor burnout detection

Safety Certification:Up to SIL 2 acc. to IEC 61508/IEC 61511

Operating Range:20…30 V DC

Operating Weight:approx. 130 g

Operating Dimensions:20 x 119 x 115 mm

    Introducing the Pepperl+Fuchs KFD2-UT2-EX1 Temperature Converter, engineered for the most challenging industrial environments. This compact converter ensures precise temperature measurements across a wide range of applications, from process control to HVAC systems.

    With its robust design, this unit can handle extreme conditions without compromising performance or accuracy. The inclusion of a 1-channel isolated barrier provides enhanced safety and reduces interference, ensuring reliable operation even in noisy environments.

    Equipped with a versatile 24 V DC supply and configurable outputs, the KFD2-UT2-EX1 allows seamless integration into existing systems. Its ability to accept thermocouple, RTD, potentiometer, or voltage inputs makes it highly adaptable to various measurement requirements.

    The current output feature supports a flexible range of 0/4 mA to 20 mA, offering the precision needed for accurate data transmission. Whether you require a sink or source mode, this converter delivers, thanks to its programmable settings via PACTware software.

    Incorporating advanced fault detection capabilities, including line fault (LFD) and sensor burnout detection, ensures continuous monitoring and alerts for maintenance needs, minimizing downtime and maximizing operational efficiency.
