Detection type:Photoelectric sampling

Device type:Multiturn absolute encoder

Operating voltage:4.5 … 30 V DC (SSI, SSI + RS422); 10 … 30 V DC (SSI + Push/Pull)

Output code:Gray code, binary code

Connector:Type 9416 (M23), 12-pin; Type 9416L (M23), 12-pin

Pulses:1024, 2048, 4096

Mass:Approx. 460 g (combination 1); approx. 800 g (combination 2)

    The P+F PVM58I-032AGR0BN-1213 encoder is meticulously crafted for applications requiring precise angular position measurement and feedback. It features an industrial-standard housing with a compact design of ∅58 mm, ensuring easy integration into existing machinery.

    Equipped with a PROFIBUS interface, this encoder supports seamless communication in industrial automation networks, enhancing system reliability and efficiency. The extended scaling functions and programmable limit switches provide flexibility for various operational scenarios.

    Utilizing photoelectric sampling technology, the PVM58I-032AGR0BN-1213 encoder ensures accurate detection and conversion of mechanical movements into digital signals, critical for the smooth operation of automation systems.

    With a robust construction and operating voltage range from 4.5 to 30 V DC, this encoder is suitable for diverse industrial settings, ensuring reliable performance under varying conditions. The binary or gray code output options cater to different integration requirements.

    The inclusion of a connector compatible with both M23 types facilitates straightforward installation and maintenance. This encoder is a reliable choice for applications demanding precision, durability, and compatibility with standard automation protocols.
