Connectable Units:8

Unit Output Power Supply:24 VDC, 1.2 A max.

Rated Voltage:24 VDC (20.4 to 28.8 VDC)

Current Consumption:0.10 A

Dielectric Strength:500 VAC for 1 min

Mounting Method:DIN 35 mm-track mounting

Certifications:UL, cULus, CE, CSA, KC

    The Omron C200HW-BC031 8-Slot Backplane offers an efficient and reliable solution for connecting up to eight modules in compact PLC systems. Designed specifically for industrial automation environments, this backplane ensures stable communication between the PLC and its connected modules.

    This model complies with a wide range of international safety standards including UL, U1, cULus, cUL, CSA, CE, and KC. These certifications guarantee the product’s reliability and performance in diverse working conditions, especially in hazardous locations.

    The unit output power supply is rated at 0.4 A maximum, ensuring ample power for each module without overloading. With a dielectric strength of 500 VAC for one minute, the backplane provides robust insulation, protecting against electrical surges and ensuring consistent operation.

    Installation is straightforward thanks to the DIN 35 mm-track mounting method, which facilitates quick and secure attachment to standard control panels and cabinets. This feature simplifies setup and maintenance processes, saving time and reducing complexity.

    Designed with durability in mind, the C200HW-BC031 backplane is built to withstand the harsh environments commonly found in industrial settings. Its robust construction and proven performance make it a trusted choice for engineers and technicians looking for dependable solutions in their automation projects.
