NI SCXI-1520 High-Performance Industrial Signal Conditioning Module
The NI SCXI-1520 is a high-performance analog input module designed for industrial automation and control systems. It provides precise measurements for a wide range of applications including process control, data acquisition, and monitoring.
Detailed content
Brand:NI
Model:SCXI-1520
Module Type:Data Acquisition Module
Input Channels:8 differential or 16 single-ended
Resolution:16 bits
Sampling Rate:Up to 1 MS/s per channel
Input Range:+/- 10V
Analog Output:No
Digital I/O:No
Interface:SCXI-1100 Chassis
Certification:Compliant with IEEE 1451.2 Smart Transducer Interface Standard
The NI SCXI-1520 is a versatile signal conditioning module tailored for industrial environments where precision and reliability are paramount. This module is designed to accurately measure voltages within a wide range of +/-10V, ensuring data integrity across various applications. With its high resolution of 16 bits and exceptional accuracy of +/-0.025% of reading + 10uV, the SCXI-1520 delivers reliable performance even under demanding conditions. Featuring eight channels, this module allows for efficient data collection and monitoring. Its screw terminal connectors offer secure and easy wiring, while the external DC power supply ensures stable operation. Operating over a broad temperature range from -40°C to +85°C, the SCXI-1520 is built to withstand harsh industrial environments. Additionally, compliance with CE and RoHS certifications guarantees safety and environmental standards.
