1. Technical Specifications

• Model: NI SCXI-1104C
• Type: Signal Conditioning Module
• Form Factor: SCXI (Signal Conditioning eXtensions for Instrumentation)
• Channels:
  • Number of Channels: 16 single-ended or 8 differential channels
• Input Types:
  • Analog Inputs: Voltage inputs
• Input Range:
  • Voltage Range: ±10 V
• Accuracy:
  • Resolution: 16-bit
  • Accuracy: ±0.05% of full-scale range
• Input Impedance:
  • Voltage Input Impedance: 10 MΩ
• Signal Conditioning:
  • Gain: Programmable gain (up to 1000x)
  • Filtering: Built-in low-pass filters to reduce noise and improve signal quality
• Sampling Rate:
  • Maximum Sampling Rate: Up to 100 kS/s (kilo samples per second)

2. Key Features

• Versatile Signal Conditioning: Provides comprehensive signal conditioning including amplification and filtering, suitable for a variety of measurement applications.
• High Accuracy and Resolution: Ensures precise data acquisition with high-resolution and accurate measurements.
• Flexible Configuration: Supports both single-ended and differential configurations for versatile signal measurement.
• Built-In Filtering: Includes low-pass filtering to reduce noise and improve signal clarity.
• Compatibility: Designed to integrate seamlessly with National Instruments’ SCXI system and compatible with LabVIEW software for easy setup and control.

3. Application Scenarios

• Data Acquisition Systems: Used in laboratory and industrial data acquisition systems for accurate measurement of analog signals.
• Measurement and Testing: Ideal for applications requiring high precision, such as research and development, testing, and quality control.
• Signal Conditioning: Suitable for conditioning signals from various sensors, including temperature sensors, pressure transducers, and strain gauges.
• Industrial Monitoring: Applied in industrial environments for monitoring and analyzing signals from machinery and equipment.

4. Additional Information

• Software Integration: Fully compatible with National Instruments’ software platforms, including LabVIEW and NI-DAQmx, for comprehensive data acquisition and control.
• Installation: Fits into an SCXI chassis, which is connected to a PXI or PCI data acquisition system.
• Technical Support: For more detailed specifications, installation instructions, and technical assistance, refer to the official datasheet or contact National Instruments.
