Technical Specifications

1. Processor:
   • Type: Intel Core i7-4700EQ
   • Cores/Threads: 4 cores, 8 threads
   • Base Frequency: 2.4 GHz
   • Max Turbo Frequency: 3.4 GHz
   • Cache: 6 MB Intel Smart Cache
2. Memory:
   • RAM: 8 GB DDR3L (upgradable)
   • Type: DDR3L 1600 MHz
3. Storage:
   • Internal Storage: 128 GB SSD (Solid State Drive)
   • Additional Storage: SATA interface available for additional storage options
4. I/O Interfaces:
   • USB Ports: 4x USB 3.0, 2x USB 2.0
   • Ethernet Ports: 2x Gigabit Ethernet (RJ-45)
   • Serial Ports: 1x RS-232
   • Digital I/O: Available through PXI Express backplane
5. PXI Express Interface:
   • Slots: 1x PXI Express system slot
   • Bus: PXI Express (PXIe)
6. Graphics:
   • Type: Integrated Intel HD Graphics 4600
   • Resolution: Supports up to 2560×1600 at 60 Hz
7. Operating System:
   • Pre-installed OS: Windows 10 IoT Enterprise (or other Windows versions depending on configuration)
8. Power Supply:
   • Power Requirements: Supplied through the PXI Express chassis
9. Physical Dimensions:
   • Form Factor: 3U PXI Express
   • Dimensions: 128.4 mm x 40.6 mm x 160.0 mm (W x H x D)
10. Temperature Range:
    • Operating Temperature: 0°C to 55°C
    • Storage Temperature: -20°C to 70°C

Key Features

1. High Performance: The Intel Core i7 processor provides robust processing capabilities suitable for demanding applications.
2. Flexibility: Multiple I/O options including USB, Ethernet, and serial ports allow integration with a variety of external devices and networks.
3. Scalability: The ability to add additional storage and memory allows customization based on application needs.
4. Embedded Functionality: Designed to function as a standalone controller within a PXI Express system, eliminating the need for an external PC.
5. Compact Size: The 3U form factor ensures it fits into standard PXI Express chassis, optimizing space within test and measurement setups.

Applications

1. Automated Test Systems: Ideal for use in automated test setups where high processing power and reliability are crucial.
2. Data Acquisition: Suitable for high-speed data acquisition systems requiring robust and flexible processing capabilities.
3. Simulation: Effective in simulation environments where real-time processing and control are necessary.
4. Industrial Automation: Can be used in industrial settings for control and monitoring applications due to its durability and performance.
5. Research and Development: Useful for R&D projects needing powerful and adaptable computing resources within a test system.
