Technical Specifications

• Form Factor:
  • Type: PXIe Chassis Controller
  • Slot Compatibility: Fits into a PXIe chassis slot
• Processor:
  • CPU: Intel Core i7-8700
  • Number of Cores: 6 cores, 12 threads
• Memory:
  • RAM: 32 GB of DDR4 memory
• Storage:
  • Hard Drive: 512 GB SSD (Solid State Drive)
  • Additional Storage: Supports additional external storage if needed
• Connectivity:
  • Ethernet: Dual Gigabit Ethernet ports
  • USB Ports: Multiple USB 3.1 and USB 2.0 ports
  • Serial Ports: RS-232 serial port
  • PCIe: PXIe interface for integration with PXIe modules
  • Display Ports: Dual DisplayPort outputs
• Operating System:
  • OS Compatibility: Windows 10 IoT Enterprise, Windows 7 (64-bit)
  • NI Software: Compatible with National Instruments software platforms, including LabVIEW and NI Measurement & Automation Explorer (MAX)
• Power Requirements:
  • Power Supply: Powered through the PXIe chassis
• Cooling:
  • Cooling Mechanism: Internal cooling systems to maintain optimal operating temperatures

Functional Features

• High-Performance Processing:
  • Processor: Features an Intel Core i7-8700 processor with 6 cores and 12 threads, providing robust computational power for handling complex and high-throughput tasks.
• Enhanced Memory and Storage:
  • RAM: 32 GB of DDR4 memory supports extensive multitasking and large dataset handling.
  • Storage: 512 GB SSD provides high-speed data access and ample storage capacity.
• Advanced Connectivity:
  • Ethernet: Dual Gigabit Ethernet ports offer reliable and high-speed network connections.
  • USB Ports: Multiple USB 3.1 and USB 2.0 ports support high-speed data transfer and various peripherals.
  • Serial Ports: RS-232 port for communication with legacy devices.
  • Display Ports: Dual DisplayPort outputs for connecting multiple monitors and enhancing visual workspace.
• Integrated PXIe Interface:
  • Function: The PXIe interface supports high-speed communication and control of PXIe modules, facilitating efficient data handling and system management.
• Software Compatibility:
  • NI Integration: Fully compatible with National Instruments software such as LabVIEW for programming and NI MAX for configuration and management.
• Scalable and Modular:
  • Design: Designed to fit within a PXIe system, supporting flexible expansion and customization to meet specific needs.

Application Scenarios

• Test and Measurement Systems:
  • Use Case: Serves as the central controller for PXIe-based test and measurement systems, managing data acquisition, processing, and coordination of multiple PXIe modules.
• High-Speed Data Acquisition:
  • Integration: Suitable for applications requiring high-speed data acquisition and substantial processing capabilities.
• Automated Testing:
  • Functionality: Ideal for managing automated test systems, offering precise timing, synchronization, and control of PXIe modules.
• Embedded Control:
  • Deployment: Can be utilized in embedded control systems where real-time processing and integration with PXIe modules are necessary.
• Research and Development:
  • Applications: Supports complex R&D projects that involve sophisticated test systems, data acquisition setups, and experimental controls.
