Technical Specifications

• Form Factor:
  • Type: PXIe Chassis Controller
  • Slot Compatibility: Fits into a PXIe chassis slot
• Processor:
  • CPU: Intel Core i7-8700
  • Number of Cores: 6 cores, 12 threads
• Memory:
  • RAM: 16 GB of DDR4 memory
• Storage:
  • Hard Drive: 256 GB SSD (Solid State Drive)
  • Additional Storage: Supports additional external storage if needed
• Connectivity:
  • Ethernet: Dual Gigabit Ethernet ports
  • USB Ports: Multiple USB 3.1 and USB 2.0 ports
  • Serial Ports: RS-232 serial port
  • PCIe: PXIe interface for integration with PXIe modules
• Operating System:
  • OS Compatibility: Windows 10 IoT Enterprise, Windows 7 (64-bit)
  • NI Software: Compatible with National Instruments software platforms, such as LabVIEW and NI Measurement & Automation Explorer (MAX)
• Power Requirements:
  • Power Supply: Powered through the PXIe chassis
• Cooling:
  • Cooling Mechanism: Features internal cooling systems to ensure optimal operating temperatures

Functional Features

• High-Performance Processing:
  • Processor: The Intel Core i7-8700 processor provides 6 cores and 12 threads, delivering substantial computational power suitable for handling complex data and tasks.
• Memory and Storage:
  • RAM: 16 GB of DDR4 memory facilitates multitasking and efficient data handling.
  • Storage: 256 GB SSD offers fast data access and reliable performance.
• Advanced Connectivity:
  • Ethernet: Dual Gigabit Ethernet ports enable high-speed network connections and reliable data transfer.
  • USB Ports: Multiple USB 3.1 and USB 2.0 ports support various peripherals and high-speed data transfer.
  • Serial Ports: RS-232 serial port for communication with legacy devices and serial equipment.
• Integrated PXIe Interface:
  • Function: The PXIe interface ensures efficient communication and control of PXIe modules, providing high-speed data handling and system integration.
• Software Compatibility:
  • NI Integration: Fully compatible with National Instruments software platforms, including LabVIEW for system programming and NI Measurement & Automation Explorer (MAX) for system configuration and management.
• Scalable and Modular:
  • Design: As part of a PXIe system, the PXIe-8822 supports flexible expansion and customization to meet specific application needs.

Application Scenarios

• Test and Measurement Systems:
  • Use Case: Acts as the central controller for PXIe-based test and measurement systems, managing data acquisition, processing, and coordination of multiple PXIe modules.
• High-Speed Data Acquisition:
  • Integration: Ideal for high-speed data acquisition applications requiring substantial processing power and connectivity.
• Automated Testing:
  • Functionality: Suitable for managing automated test systems, providing precise timing, synchronization, and control of PXIe modules.
• Embedded Control:
  • Deployment: Can be used in embedded control systems that require real-time processing and integration with PXIe modules.
• Research and Development:
  • Applications: Supports advanced R&D projects that involve complex test systems, data acquisition setups, and experimental controls.
