Technical Specifications

• Form Factor:
  • Type: PXIe Chassis Controller
  • Slot Compatibility: Fits into a PXIe chassis slot
• Processor:
  • CPU: Intel Core i7-8700
  • Number of Cores: 6 cores, 12 threads
• Memory:
  • RAM: 16 GB of DDR4 memory
• Storage:
  • Hard Drive: 256 GB SSD (Solid State Drive)
  • Additional Storage: Supports additional external storage if needed
• Connectivity:
  • Ethernet: Dual Gigabit Ethernet ports
  • USB Ports: Multiple USB 3.1 and USB 2.0 ports
  • Serial Ports: RS-232 serial port
  • PCIe: PXIe interface for integration with PXIe modules
• Operating System:
  • OS Compatibility: Windows 10 IoT Enterprise, Windows 7 (64-bit)
  • NI Software: Compatible with National Instruments software platforms, such as LabVIEW and NI Measurement & Automation Explorer (MAX)
• Power Requirements:
  • Power Supply: Powered through the PXIe chassis
• Cooling:
  • Cooling Mechanism: Includes internal cooling systems to maintain optimal operating temperatures

Functional Features

• High-Performance Processing:
  • Processor: Features an Intel Core i7-8700 processor with 6 cores and 12 threads, providing substantial computational power for a wide range of applications.
• Memory and Storage:
  • RAM: 16 GB of DDR4 memory supports multitasking and efficient handling of data.
  • Storage: 256 GB SSD ensures fast data access and reliable storage performance.
• Advanced Connectivity:
  • Ethernet: Dual Gigabit Ethernet ports offer high-speed network connections for reliable data transfer.
  • USB Ports: Multiple USB 3.1 and USB 2.0 ports support various peripherals and high-speed data transfer needs.
  • Serial Ports: RS-232 port for communication with legacy equipment and other serial devices.
• Integrated PXIe Interface:
  • Function: The PXIe interface facilitates high-speed communication and control of PXIe modules, ensuring efficient data management and system integration.
• Software Compatibility:
  • NI Integration: Fully compatible with National Instruments software platforms like LabVIEW for programming and NI MAX for system configuration and management.
• Scalable and Modular:
  • Design: As part of a modular PXIe system, the PXIe-8821 supports flexible expansion and customization based on specific application requirements.

Application Scenarios

• Test and Measurement Systems:
  • Use Case: Acts as the central controller in PXIe-based test and measurement systems, managing data acquisition, processing, and coordination of multiple PXIe modules.
• High-Speed Data Acquisition:
  • Integration: Suitable for high-speed data acquisition tasks requiring significant processing capabilities and robust connectivity.
• Automated Testing:
  • Functionality: Ideal for managing automated test systems, providing precise timing, synchronization, and control of PXIe modules.
• Embedded Control:
  • Deployment: Can be utilized in embedded control systems where real-time processing and integration with PXIe modules are required.
• Research and Development:
  • Applications: Supports complex R&D projects involving advanced test systems, data acquisition setups, and experimental controls.
