Technical Specifications

• Form Factor:
  • Type: PXIe Chassis Controller
  • Slot Compatibility: Fits into a PXIe chassis slot
• Processor:
  • CPU: Intel Xeon E-2288G processor
  • Number of Cores: 8 cores, 16 threads
• Memory:
  • RAM: 32 GB of DDR4 memory
• Storage:
  • Hard Drive: 1 TB SSD (Solid State Drive)
  • Additional Storage: Supports additional external storage options if needed
• Connectivity:
  • Ethernet: Dual Gigabit Ethernet ports
  • USB Ports: Multiple USB 3.0 and USB 2.0 ports
  • Serial Ports: RS-232 and RS-485 serial ports
  • PCIe: PXIe interface for integration with PXIe modules
• Operating System:
  • OS Compatibility: Windows 10 IoT Enterprise, Windows 7 (64-bit)
  • NI Software: Compatible with National Instruments software platforms, such as LabVIEW and NI Measurement & Automation Explorer (MAX)
• Power Requirements:
  • Power Supply: Powered through the PXIe chassis
• Cooling:
  • Cooling Mechanism: Equipped with internal cooling systems to ensure optimal operating temperatures

Functional Features

• High-Performance Processing:
  • Processor: Features an Intel Xeon E-2288G processor with 8 cores and 16 threads, providing significant computational power for demanding tasks and high-throughput data processing.
• Expanded Memory and Storage:
  • RAM: 32 GB of DDR4 memory for handling large datasets and complex computations with ease.
  • Storage: 1 TB SSD offers fast data access, ample storage capacity, and reliable performance.
• Advanced Connectivity:
  • Ethernet: Dual Gigabit Ethernet ports facilitate high-speed network connections and reliable data transfer.
  • USB Ports: Multiple USB 3.0 and USB 2.0 ports support various peripherals and high-speed data transfer.
  • Serial Ports: RS-232 and RS-485 ports allow communication with legacy equipment and other serial devices.
• Integrated PXIe Interface:
  • Function: The PXIe interface supports efficient communication and control of PXIe modules, ensuring high-speed data handling and system management.
• Software Compatibility:
  • NI Integration: Fully compatible with National Instruments software such as LabVIEW for system programming and NI MAX for configuration and management.
• Scalable and Modular:
  • Design: As part of a modular PXIe system, the PXIe-8398 allows for flexible expansion and customization based on specific application requirements.

Application Scenarios

• Test and Measurement Systems:
  • Use Case: Acts as the central controller in PXIe-based test and measurement systems, overseeing data acquisition, processing, and coordination of multiple PXIe modules.
• High-Speed Data Acquisition:
  • Integration: Suitable for high-speed data acquisition applications requiring substantial processing power and connectivity.
• Automated Testing:
  • Functionality: Ideal for managing automated test systems, providing precise timing, synchronization, and control of PXIe modules.
• Embedded Control:
  • Deployment: Can be utilized in embedded control systems requiring real-time processing and integration with PXIe modules.
• Research and Development:
  • Applications: Supports complex R&D projects that involve advanced test systems, data acquisition setups, and experimental controls.
