Technical Specifications

• Form Factor:
  • Type: PXIe Chassis Controller
  • Slot Compatibility: Fits into a PXIe chassis slot
• Processor:
  • CPU: Intel Xeon E-2276M processor
  • Number of Cores: 6 cores, 12 threads
• Memory:
  • RAM: 32 GB of DDR4 memory
• Storage:
  • Hard Drive: 1 TB SSD (Solid State Drive)
  • Additional Storage: Supports additional external storage options
• Connectivity:
  • Ethernet: Dual Gigabit Ethernet ports
  • USB Ports: Multiple USB 3.0 and USB 2.0 ports
  • Serial Ports: RS-232 and RS-485 serial ports
  • PCIe: PXIe interface for integration with PXIe modules
• Operating System:
  • OS Compatibility: Windows 10 IoT Enterprise, Windows 7 (64-bit)
  • NI Software: Compatible with National Instruments software platforms such as LabVIEW and NI Measurement & Automation Explorer (MAX)
• Power Requirements:
  • Power Supply: Powered through the PXIe chassis
• Cooling:
  • Cooling Mechanism: Includes internal cooling systems to maintain optimal operating temperatures

Functional Features

• High-Performance Processing:
  • Processor: Equipped with an Intel Xeon E-2276M processor, which provides high performance with 6 cores and 12 threads, making it suitable for demanding applications and data processing tasks.
• Expanded Memory and Storage:
  • RAM: 32 GB of DDR4 memory allows for efficient handling of large datasets and complex computations.
  • Storage: 1 TB SSD ensures rapid data access and ample storage capacity for large-scale applications.
• Advanced Connectivity:
  • Ethernet: Dual Gigabit Ethernet ports provide high-speed network connectivity for reliable data transfer.
  • USB Ports: Multiple USB 3.0 and USB 2.0 ports support a range of peripheral devices and fast data transfer.
  • Serial Ports: RS-232 and RS-485 ports for communication with legacy equipment and other serial devices.
• Integrated PXIe Interface:
  • Function: The PXIe interface allows for high-speed communication and control of PXIe modules, facilitating efficient data handling and system management.
• Software Compatibility:
  • NI Integration: Fully compatible with National Instruments software, including LabVIEW for programming and NI MAX for configuration and system management.
• Scalable and Modular:
  • Design: As part of a modular PXIe system, it allows for flexible expansion and customization to meet specific application requirements.

Application Scenarios

• Test and Measurement Systems:
  • Use Case: Serves as the central controller in PXIe-based test and measurement systems, managing data acquisition, processing, and coordination of PXIe modules.
• High-Speed Data Acquisition:
  • Integration: Ideal for high-speed data acquisition systems requiring robust processing power and connectivity.
• Automated Testing:
  • Functionality: Suitable for controlling automated test systems, providing precise timing, synchronization, and management of PXIe modules.
• Embedded Control:
  • Deployment: Can be used in embedded control applications requiring real-time processing and integration with PXIe modules.
• Research and Development:
  • Applications: Supports complex R&D projects involving advanced test systems, data acquisition setups, and experimental controls.
