Technical Specifications

• Form Factor:
  • Type: PXIe Chassis Controller
  • Slot Compatibility: Fits into PXIe chassis slots
• Processor:
  • CPU: Intel Xeon E3-1245 v6 processor
  • Number of Cores: Quad-core
• Memory:
  • RAM: 16 GB of DDR4 memory
• Storage:
  • Hard Drive: 512 GB SSD (Solid State Drive)
  • Additional Storage: Supports additional external storage options
• Connectivity:
  • Ethernet: Dual Gigabit Ethernet ports
  • USB Ports: Multiple USB 3.0 ports
  • Serial Ports: RS-232 and RS-485 serial ports
  • PCIe: PXIe interface for integration with PXIe modules
• Operating System:
  • OS Compatibility: Windows 10 IoT Enterprise, Windows 7 (64-bit)
  • NI Software: Compatible with National Instruments software platforms, including LabVIEW and NI Measurement & Automation Explorer (MAX)
• Power Requirements:
  • Power Supply: Powered through the PXIe chassis
• Cooling:
  • Cooling Mechanism: Equipped with internal cooling systems to maintain optimal operating temperatures

Functional Features

• High-Performance Processing:
  • Processor: Features an Intel Xeon E3-1245 v6 processor, providing robust performance for demanding applications and high-throughput data processing.
• Increased Memory and Storage:
  • RAM: 16 GB of DDR4 memory for efficient multitasking and handling of large datasets.
  • Storage: 512 GB SSD ensures fast data access and reliable performance.
• Advanced Connectivity:
  • Ethernet: Dual Gigabit Ethernet ports for high-speed network connections and reliable data transfer.
  • USB Ports: Multiple USB 3.0 ports for rapid peripheral connections.
  • Serial Ports: RS-232 and RS-485 ports for interfacing with legacy equipment and systems.
• Integrated PXIe Interface:
  • Function: Supports high-speed communication and control of PXIe modules, enabling efficient data transfer and system management.
• Software Compatibility:
  • NI Integration: Fully compatible with National Instruments software such as LabVIEW for system programming and NI MAX for configuration and management.
• Scalable and Modular:
  • Design: Part of a modular PXIe system, allowing for flexible expansion and customization based on application requirements.

Application Scenarios

• Test and Measurement Systems:
  • Use Case: Acts as the central controller in PXIe-based test and measurement systems, coordinating data acquisition, processing, and management of multiple PXIe modules.
• High-Speed Data Acquisition:
  • Integration: Ideal for systems requiring high-speed data acquisition with substantial processing power and connectivity.
• Automated Testing:
  • Functionality: Suitable for managing automated test systems, providing precise control, synchronization, and timing of PXIe modules.
• Embedded Control:
  • Deployment: Can be used in embedded control applications requiring real-time processing and integration with PXIe modules.
• Research and Development:
  • Applications: Supports R&D projects that involve complex test systems, data acquisition setups, and experimental controls.
