Technical Specifications

• Form Factor:
  • Type: PXIe Chassis Controller
  • Slot Compatibility: Designed for integration into PXIe chassis slots
• Processor:
  • CPU: Intel Xeon E3-1225 v6 processor
  • Number of Cores: Quad-core
• Memory:
  • RAM: 16 GB of DDR4 memory
• Storage:
  • Hard Drive: 256 GB SSD (Solid State Drive)
  • Additional Storage: Supports additional external storage options if needed
• Connectivity:
  • Ethernet: Dual Gigabit Ethernet ports
  • USB Ports: Multiple USB 3.0 ports
  • Serial Ports: RS-232 and RS-485 serial ports
  • PCIe: PXIe interface for communication and control of PXIe modules
• Operating System:
  • OS Compatibility: Windows 10 IoT Enterprise, Windows 7 (64-bit)
  • NI Software: Fully compatible with National Instruments software platforms, such as LabVIEW and NI Measurement & Automation Explorer (MAX)
• Power Requirements:
  • Power Supply: Powered through the PXIe chassis
• Cooling:
  • Cooling Mechanism: Equipped with internal cooling systems to ensure optimal operation and prevent overheating

Functional Features

• High-Performance Processing:
  • Processor: Features an Intel Xeon E3-1225 v6 processor, offering robust performance suitable for demanding applications and high-throughput data handling.
• Ample Memory and Storage:
  • RAM: 16 GB of DDR4 memory supports efficient multitasking and processing of large datasets.
  • Storage: 256 GB SSD provides fast data access and system responsiveness.
• Comprehensive Connectivity:
  • Ethernet: Dual Gigabit Ethernet ports enable high-speed network connections and reliable data transfer.
  • USB Ports: Multiple USB 3.0 ports allow for fast peripheral connections and high-speed data transfer.
  • Serial Ports: RS-232 and RS-485 ports facilitate communication with legacy equipment and devices.
• Integrated PXIe Interface:
  • Function: The PXIe interface supports efficient communication and control of PXIe modules, ensuring high-speed data transfer and system management.
• Software Compatibility:
  • NI Integration: Fully compatible with National Instruments software such as LabVIEW for system programming and NI MAX for configuration and management.
• Scalable and Modular:
  • Design: Part of a scalable PXIe system, allowing for modular expansion and customization to meet specific application needs.

Application Scenarios

• Test and Measurement Systems:
  • Use Case: Functions as the central controller in PXIe-based test and measurement systems, managing data acquisition, processing, and coordination of multiple PXIe modules.
• High-Speed Data Acquisition:
  • Integration: Ideal for applications that require high-speed data acquisition and processing with substantial connectivity and control.
• Automated Testing:
  • Functionality: Suitable for managing automated test systems, providing precise timing, synchronization, and control of PXIe modules.
• Embedded Control:
  • Deployment: Can be used in embedded control applications that require real-time processing and integration with PXIe modules.
• Research and Development:
  • Applications: Supports complex R&D projects involving sophisticated test systems, data acquisition setups, and experimental controls.
