Technical Specifications

• Form Factor:
  • Type: PXIe Chassis Controller
  • Slot Compatibility: Fits into PXIe chassis slots
• Processor:
  • CPU: Intel Core i7-6700TE processor
  • Number of Cores: Quad-core
• Memory:
  • RAM: 16 GB of DDR4 memory
• Storage:
  • Hard Drive: 256 GB SSD (Solid State Drive)
  • Additional Storage: Supports external storage solutions for additional capacity
• Connectivity:
  • Ethernet: Dual Gigabit Ethernet ports
  • USB Ports: Multiple USB 3.0 ports
  • Serial Ports: RS-232 and RS-485 serial ports
  • PCIe: PXIe interface for integration with PXIe modules
• Operating System:
  • OS Compatibility: Windows 10 IoT Enterprise, Windows 7 (64-bit)
  • NI Software: Compatible with National Instruments software platforms, such as LabVIEW and NI Measurement & Automation Explorer (MAX)
• Power Requirements:
  • Power Supply: Powered through the PXIe chassis
• Cooling:
  • Cooling Mechanism: Includes internal cooling systems to ensure proper heat dissipation

Functional Features

• High-Performance Processing:
  • Processor: Equipped with an Intel Core i7-6700TE processor, offering high performance for complex and demanding applications.
• Enhanced Memory and Storage:
  • RAM: 16 GB of DDR4 memory for efficient multitasking and handling large datasets.
  • Storage: 256 GB SSD provides fast data access and reliable system performance.
• Advanced Connectivity:
  • Ethernet: Dual Gigabit Ethernet ports for high-speed network connectivity and communication.
  • USB Ports: Includes multiple USB 3.0 ports for fast peripheral connections.
  • Serial Ports: RS-232 and RS-485 ports for interfacing with legacy devices and systems.
• Integrated PXIe Interface:
  • Function: Features a PXIe interface to connect and manage PXIe modules, ensuring high-speed data transfer and efficient system control.
• Software Compatibility:
  • NI Integration: Fully compatible with National Instruments software solutions, including LabVIEW for programming and NI MAX for system configuration.
• Scalable and Modular:
  • Design: Part of a modular PXIe system, allowing for expansion and customization based on application requirements.

Application Scenarios

• Test and Measurement Systems:
  • Use Case: Serves as the central controller in PXIe-based test and measurement systems, managing data acquisition, processing, and coordination of PXIe modules.
• Data Acquisition:
  • Integration: Ideal for high-speed data acquisition systems where processing power and connectivity are critical.
• Automated Test Systems:
  • Functionality: Suitable for managing automated test systems, providing precise timing, synchronization, and control of multiple PXIe modules.
• Embedded Control:
  • Deployment: Can be utilized in embedded control systems that require real-time processing and integration with PXIe modules.
• Research and Development:
  • Applications: Supports R&D projects involving complex test systems, data acquisition setups, and experimental control.
