Technical Specifications

• Form Factor:
  • Type: PXIe Chassis Controller
  • Slot Compatibility: Designed to fit into PXIe chassis slots
• Processor:
  • CPU: Intel Core i7-5600U processor
  • Number of Cores: Dual-core
• Memory:
  • RAM: 8 GB of DDR3L memory
• Storage:
  • Hard Drive: 128 GB SSD (Solid State Drive)
  • Additional Storage: Supports external storage options if additional capacity is needed
• Connectivity:
  • Ethernet: Dual Gigabit Ethernet ports
  • USB Ports: Multiple USB ports including USB 3.0
  • Serial Ports: RS-232 and RS-485 serial ports for legacy communication
  • PCIe: PXIe interface for integration with PXIe modules
• Operating System:
  • OS Compatibility: Windows 10 IoT Enterprise, Windows 7 (64-bit)
  • NI Software: Compatible with National Instruments software platforms like LabVIEW and NI Measurement & Automation Explorer (MAX)
• Power Requirements:
  • Power Supply: Powered through the PXIe chassis
• Cooling:
  • Cooling Mechanism: Includes internal cooling systems for effective heat dissipation

Functional Features

• High-Performance Processing:
  • Processor: Features an Intel Core i7-5600U processor, delivering high performance for demanding applications.
• Adequate Memory and Storage:
  • RAM: 8 GB of DDR3L memory supports efficient multitasking and complex applications.
  • Storage: 128 GB SSD ensures fast data access and system responsiveness.
• Comprehensive Connectivity:
  • Ethernet: Dual Gigabit Ethernet ports provide high-speed network connectivity.
  • USB Ports: Includes multiple USB 3.0 ports for high-speed peripheral connections.
  • Serial Ports: RS-232 and RS-485 serial ports enable communication with legacy equipment.
• Integrated PXIe Interface:
  • Function: Provides a PXIe interface for connecting and controlling PXIe modules, ensuring efficient data transfer and system management.
• Software Support:
  • NI Integration: Fully compatible with National Instruments software, including LabVIEW and NI MAX, for system configuration and control.
• Scalable and Modular:
  • Design: Part of a scalable PXIe system, allowing for modular expansion and flexibility based on application needs.

Application Scenarios

• Test and Measurement Systems:
  • Use Case: Acts as the central controller in PXIe-based test and measurement systems, managing data acquisition, processing, and coordination among PXIe modules.
• Data Acquisition:
  • Integration: Suitable for high-speed data acquisition systems requiring robust processing power and connectivity.
• Automated Test Systems:
  • Functionality: Ideal for managing automated test systems, ensuring precise timing, synchronization, and control of multiple PXIe modules.
• Embedded Control:
  • Deployment: Can be used in embedded control systems where real-time processing and module integration are essential.
• Research and Development:
  • Applications: Supports R&D projects involving complex test systems, data acquisition setups, and experimental controls.
