Technical Specifications

• Form Factor:
  • Type: PXIe Controller Module
  • Slot Compatibility: Designed to fit into PXIe chassis slots
• Processor:
  • CPU: Intel Core i7-6820EQ processor
  • Number of Cores: Quad-core
• Memory:
  • RAM: 16 GB of DDR4 memory
• Storage:
  • Hard Drive: 256 GB SSD (Solid State Drive)
  • Additional Storage: Supports external storage solutions if additional capacity is needed
• Connectivity:
  • Ethernet: Dual Gigabit Ethernet ports
  • USB Ports: Multiple USB ports, including USB 3.0
  • Serial Ports: RS-232/RS-485 serial ports for legacy communication
  • PCIe: PXIe interface for connecting and controlling PXIe modules and systems
• Operating System:
  • OS Compatibility: Windows 10 IoT Enterprise, Windows 7 (64-bit)
  • NI Software: Fully supported by National Instruments software such as LabVIEW and NI Measurement & Automation Explorer (MAX)
• Power Requirements:
  • Power Supply: Powered through the PXIe chassis
• Cooling:
  • Cooling Mechanism: Includes internal cooling systems to ensure proper heat dissipation

Functional Features

• High-Performance Processing:
  • Processor: Equipped with an Intel Core i7-6820EQ processor, providing high performance for demanding tasks and applications.
• Enhanced Memory and Storage:
  • RAM: 16 GB of DDR4 memory allows for efficient multitasking and handling of complex applications.
  • Storage: Fast SSD storage with 256 GB capacity for quick data access and improved system performance.
• Advanced Connectivity:
  • Ethernet: Dual Gigabit Ethernet ports support high-speed network connectivity.
  • USB Ports: Multiple USB 3.0 ports for high-speed peripheral connections.
  • Serial Ports: RS-232/RS-485 ports for communication with legacy devices.
• Integrated PXIe Interface:
  • Function: Provides a high-speed interface for integrating and controlling PXIe modules, ensuring smooth data transfer and system operation.
• Software Compatibility:
  • NI Integration: Compatible with National Instruments’ software platforms, facilitating system configuration, programming, and control.
• Scalable and Modular:
  • Design: Part of a scalable PXIe system, allowing for modular expansion and adaptation based on application needs.

Application Scenarios

• Test and Measurement Systems:
  • Use Case: Functions as the central controller in PXIe-based test and measurement systems, managing data acquisition, processing, and overall system coordination.
• Data Acquisition:
  • Integration: Suitable for high-speed data acquisition systems where robust processing power and connectivity are crucial.
• Automated Test Systems:
  • Functionality: Ideal for controlling automated test systems that require precise timing, synchronization, and management of multiple PXIe modules.
• Embedded Control:
  • Deployment: Can be used in embedded control systems where real-time processing and control are needed.
• Research and Development:
  • Applications: Supports R&D projects involving complex test systems, data acquisition setups, and experimental control scenarios.
