Technical Specifications

• Form Factor:
  • Type: PXIe Controller Module
  • Slot Compatibility: PXIe chassis
• Processor:
  • CPU: Intel Core i7 processor (specific model may vary by version)
  • Number of Cores: Typically, quad-core
• Memory:
  • RAM: 8 GB of DDR3 memory (expandable options may be available depending on the specific configuration)
• Storage:
  • Hard Drive: Solid State Drive (SSD) with various storage capacities (e.g., 128 GB, 256 GB)
  • Additional Storage: Supports additional external storage options if needed
• Connectivity:
  • Ethernet: Gigabit Ethernet port(s) for network connectivity
  • USB Ports: Multiple USB ports (e.g., USB 2.0, USB 3.0)
  • Serial Ports: RS-232 or RS-485 serial ports may be included for legacy communication
  • PCIe: Dedicated PXIe interface for connecting to PXIe modules
• Operating System:
  • OS Compatibility: Typically supports Windows operating systems (e.g., Windows 10, Windows 7)
  • NI Software: Compatible with National Instruments software such as LabVIEW and NI MAX
• Power Requirements:
  • Power Supply: Powered through the PXIe chassis
• Cooling:
  • Cooling Mechanism: Includes internal cooling systems to manage heat dissipation

Functional Features

• Integrated Controller:
  • Function: Acts as the central controller for the PXIe system, managing data transfer and communication between modules and the host system.
• High Performance:
  • Processor: Equipped with a powerful Intel Core i7 processor to handle demanding tasks and applications efficiently.
• Expansion and Connectivity:
  • Flexibility: Provides multiple connectivity options, including Ethernet, USB, and serial ports, allowing integration with a variety of peripherals and external devices.
• Software Compatibility:
  • NI Software: Fully supported by National Instruments software platforms, including LabVIEW and NI Measurement & Automation Explorer (MAX), facilitating system configuration and programming.
• Storage and Memory:
  • High-Speed Storage: Features SSD storage for fast data access and retrieval, with options for expansion based on application needs.
  • Adequate RAM: Includes sufficient memory to support complex data processing and multitasking.

Application Scenarios

• Test and Measurement Systems:
  • Use Case: Acts as the central controller in PXIe-based test and measurement systems, managing data acquisition, processing, and analysis.
• Data Acquisition:
  • Integration: Suitable for use in systems requiring high-speed data acquisition and processing, supporting real-time applications.
• Automated Test Systems:
  • Functionality: Ideal for controlling automated test systems where precise timing and synchronization with PXIe modules are critical.
• Embedded Control:
  • Deployment: Can be deployed in embedded control systems where PXIe modules are used for real-time control and monitoring tasks.
• Research and Development:
  • Applications: Used in R&D environments for building and managing test systems, data acquisition setups, and experimental control systems.
