Technical Specifications

• Number of Channels:
  • Total Channels: 64 analog output channels
• Resolution:
  • Resolution: 16 bits per channel
• Output Voltage Range:
  • Voltage Range: ±10 V (bipolar), or 0 to 10 V (unipolar), programmable per channel
• Output Characteristics:
  • Output Drive Current: 10 mA per channel
• Update Rate:
  • Maximum Update Rate: Up to 1 MHz per channel, with synchronized updates across all channels
• Synchronization:
  • Triggering: Supports both hardware and software triggering
  • Synchronization: Capable of synchronized updates across multiple channels and modules
• Connectivity:
  • Connector Type: 68-pin VHDCI (Very High Density Cable Interconnect) connector
• Bus Interface:
  • PXIe interface for seamless integration with other PXIe modules and systems
• Software Support:
  • Compatible with NI LabVIEW and other National Instruments software platforms
  • Includes drivers and APIs for integration into custom applications
• Power Requirements:
  • Voltage: 3.3 V and 5 V provided through the PXIe backplane

Functional Features

• High-Resolution DAC:
  • Offers 16-bit resolution per channel for generating precise analog signals, enabling detailed waveform generation and signal output.
• Large Channel Count:
  • Provides 64 analog output channels, allowing for extensive signal generation tasks and complex multi-channel applications.
• Flexible Voltage Output:
  • Supports programmable output voltage ranges, including both bipolar and unipolar configurations, for versatile signal generation needs.
• High-Speed Update Rate:
  • Capable of updating signals at rates up to 1 MHz per channel, suitable for real-time applications and dynamic signal requirements.
• Synchronized Outputs:
  • Features synchronized updates across all channels to ensure coherent signal generation in multi-channel systems.
• Precise Triggering and Synchronization:
  • Includes high-resolution triggering and synchronization features for accurate control and integration with other system components.
• Robust Connectivity:
  • Utilizes a 68-pin VHDCI connector for reliable and high-density connections.
• Software Integration:
  • Fully supported by NI LabVIEW and other National Instruments software platforms, facilitating easy programming, control, and data analysis.

Application Scenarios

• High-Speed Signal Generation:
  • Ideal for applications requiring precise and fast analog signal generation, such as waveform simulation and signal conditioning.
• Automated Test Systems:
  • Used in automated testing environments to provide accurate analog signals for stimulating devices under test (DUT) and collecting data.
• Complex Data Acquisition Systems:
  • Integrates into data acquisition systems that need high-density analog output for signal processing and analysis.
• Control Systems:
  • Suitable for control applications requiring multiple analog outputs to drive actuators, sensors, or other devices.
• Simulation and Modeling:
  • Useful for simulating complex systems or physical phenomena by generating synchronized analog signals.
• Research and Development:
  • Beneficial for R&D projects that involve analog signal generation, system prototyping, and testing.
