Technical Specifications

• Number of Channels:
  • Total Channels: 32 analog output channels
• Resolution:
  • Resolution: 16 bits per channel
• Output Voltage Range:
  • Voltage Range: ±10 V (bipolar), or 0 to 10 V (unipolar), programmable
• Output Characteristics:
  • Output Drive Current: 10 mA per channel
• Update Rate:
  • Maximum Update Rate: Up to 1 MHz per channel, with synchronized updates across all channels
• Synchronization:
  • Triggering: Supports hardware and software triggering for precise control
  • Synchronization: Capable of synchronized updates across multiple channels and modules
• Connectivity:
  • Connector Type: 68-pin VHDCI (Very High Density Cable Interconnect) connector
• Bus Interface:
  • PXIe interface for integration with other PXIe modules and systems
• Software Support:
  • Compatible with NI LabVIEW and other National Instruments software platforms for programming and control
  • Includes drivers and APIs for seamless integration into custom applications
• Power Requirements:
  • Voltage: 3.3 V and 5 V provided through the PXIe backplane

Functional Features

• High-Resolution DAC:
  • Provides 16-bit resolution for accurate analog signal generation, enabling precise waveform and signal output.
• Multiple Output Channels:
  • Offers 32 analog output channels, allowing for complex signal generation and multi-channel applications.
• Flexible Voltage Range:
  • Supports programmable output voltage ranges, including both bipolar and unipolar configurations, for versatile signal generation.
• High Update Rate:
  • Capable of high-speed updates with rates up to 1 MHz per channel, suitable for real-time applications and dynamic signal changes.
• Synchronized Outputs:
  • Provides synchronized updates across all channels for coherent and accurate signal generation in multi-channel systems.
• Precise Triggering and Synchronization:
  • Includes hardware and software triggering options, as well as synchronization capabilities for integrating with other system components.
• Compact and Reliable Connector:
  • Utilizes a 68-pin VHDCI connector for reliable and high-density signal connections.
• Software Integration:
  • Fully supported by NI LabVIEW and other National Instruments software, facilitating easy programming, control, and data analysis.

Application Scenarios

• Signal Generation:
  • Ideal for generating precise analog signals for testing and simulating electronic systems, including waveform generation and signal conditioning.
• Automated Testing:
  • Used in automated test systems to provide high-speed and accurate analog signals for device under test (DUT) stimulation and data acquisition.
• Data Acquisition Systems:
  • Integrates into data acquisition systems where accurate analog output is required for signal processing and analysis.
• Control Systems:
  • Useful in control systems that require high-precision analog outputs for driving actuators, sensors, or other components.
• Simulation:
  • Suitable for simulating various physical phenomena by generating accurate and synchronized analog signals.
• Research and Development:
  • Beneficial for R&D projects involving analog signal generation, system testing, and prototype development.
