Technical Specifications

• Frequency Range:
  • Output Frequency Range: 9 kHz to 9 GHz
• Output Power:
  • Power Range: -60 dBm to +15 dBm (with 0 dB attenuation at 1 GHz)
• Frequency Resolution:
  • 1 Hz
• Signal Bandwidth:
  • Up to 40 MHz
• Phase Noise:
  • Typical Phase Noise: -130 dBc/Hz at 1 GHz, 10 kHz offset
• Harmonic Distortion:
  • Typical Harmonic Distortion: -60 dBc at 1 GHz, +15 dBm
• Modulation Capabilities:
  • Supports AM (Amplitude Modulation), FM (Frequency Modulation), PM (Phase Modulation), and pulse modulation
• Output Impedance:
  • 50 Ω
• Connectivity:
  • PXIe interface for integration with other PXIe modules and systems
• Calibration:
  • Internal calibration to maintain long-term accuracy and stability

Functional Features

• Extended Frequency Range:
  • The PXIe-5698 covers an extensive frequency range from 9 kHz to 9 GHz, making it suitable for a wide array of RF and microwave applications.
• High Output Power:
  • Provides output power ranging from -60 dBm to +15 dBm, offering flexibility in signal amplitude to meet various testing requirements.
• Advanced Modulation:
  • Capable of generating signals with various modulation schemes, including AM, FM, PM, and pulse modulation, enhancing its versatility for diverse applications.
• Exceptional Signal Purity:
  • Offers high signal purity with low phase noise and harmonic distortion, ensuring clean and accurate signal generation.
• Precision Frequency Control:
  • Features precise frequency control with a resolution of 1 Hz, essential for accurate signal generation and testing.
• Flexible Bandwidth:
  • Capable of generating signals with bandwidths up to 40 MHz, accommodating various testing and simulation needs.
• Software Integration:
  • Integrates seamlessly with NI LabVIEW and other National Instruments software platforms, facilitating efficient programming, control, and comprehensive data analysis.

Application Scenarios

• RF and Microwave Testing:
  • Ideal for generating RF signals for testing and validating RF components, systems, and devices, including those operating in higher frequency ranges.
• Communications Systems:
  • Suitable for generating signals for various communications systems, including cellular, satellite, and wireless technologies, especially those operating up to 9 GHz.
• Signal Simulation:
  • Useful for simulating a broad range of RF signals in laboratory settings, assisting in the development and testing of new technologies.
• Automated Test Systems:
  • Can be integrated into automated test systems for production testing, providing reliable and accurate RF signal generation.
• Radar and Electronic Warfare:
  • Employed in radar and electronic warfare applications for generating complex signals and simulating various operational scenarios.
• Research and Development:
  • Beneficial in R&D environments for creating and analyzing test signals, validating designs, and advancing new RF technologies.
