Technical Specifications

• Frequency Range:
  • Output Frequency Range: 9 kHz to 6 GHz
• Output Power:
  • Power Range: -50 dBm to +15 dBm (at 1 GHz with 0 dB attenuation)
• Frequency Resolution:
  • 1 Hz
• Signal Bandwidth:
  • Up to 40 MHz
• Phase Noise:
  • Typical Phase Noise: -120 dBc/Hz at 1 GHz, 20 kHz offset
• Harmonic Distortion:
  • Typical Harmonic Distortion: -60 dBc at 1 GHz, +15 dBm
• Modulation Capabilities:
  • Supports AM (Amplitude Modulation), FM (Frequency Modulation), PM (Phase Modulation), and pulse modulation
• Output Impedance:
  • 50 Ω
• Connectivity:
  • PXIe interface for integration with other PXIe modules and systems
• Calibration:
  • Internal calibration ensures long-term accuracy and stability

Functional Features

• Wide Frequency Range:
  • The PXIe-5673E provides a comprehensive frequency range from 9 kHz to 6 GHz, suitable for a broad spectrum of RF and microwave applications.
• High Output Power:
  • Delivers output power from -50 dBm to +15 dBm, providing flexibility in signal amplitude for different test scenarios.
• Advanced Modulation:
  • Capable of generating signals with various modulation schemes including AM, FM, PM, and pulse modulation, enhancing its versatility for different applications.
• Excellent Signal Purity:
  • Ensures high-quality signal generation with low phase noise and harmonic distortion, critical for accurate and reliable testing.
• Precision Frequency Control:
  • Offers precise frequency control with a resolution of 1 Hz, enabling accurate signal generation and tuning.
• Flexible Bandwidth:
  • Generates signals with bandwidths up to 40 MHz, accommodating various testing and simulation requirements.
• Software Integration:
  • Seamlessly integrates with NI LabVIEW and other National Instruments software platforms, facilitating efficient programming, control, and data analysis.

Application Scenarios

• RF and Microwave Testing:
  • Ideal for generating RF signals for testing and validating components, systems, and devices across a wide frequency range.
• Communications Systems:
  • Suitable for generating signals for testing various communication systems including cellular, satellite, and wireless technologies.
• Signal Simulation:
  • Useful for simulating a range of RF signals in laboratory settings, aiding in the development and evaluation of new technologies.
• Automated Test Systems:
  • Can be integrated into automated test systems for production testing, ensuring reliable and precise RF signal generation.
• Radar and Electronic Warfare:
  • Employed in radar and electronic warfare systems to generate complex signals and simulate different operational scenarios.
• Research and Development:
  • Beneficial in R&D environments for creating and analyzing test signals, validating designs, and advancing new RF technologies.
