Technical Specifications

• Channels:
  • 2 channels per module
• Frequency Range:
  • RF Input Frequency Range: 1 MHz to 6 GHz
• Resolution Bandwidth (RBW):
  • 1 Hz to 40 MHz (selectable)
• Dynamic Range:
  • Typical Displayed Average Noise Level (DANL): -160 dBm/Hz (at 1 GHz, 10 MHz RBW)
• Sampling Rate:
  • 5 GS/s (gigasamples per second)
• Vertical Resolution:
  • 14 bits
• Input Coupling:
  • AC coupling
• Input Impedance:
  • 50 Ω
• Memory Depth:
  • Up to 512 MB (megabytes)
• Triggering:
  • Advanced triggering capabilities including edge, pulse width, and complex conditions
• Connectivity:
  • PXIe interface for seamless integration with other PXIe instruments

Functional Features

• Wide Frequency Range:
  • Covers RF input frequencies from 1 MHz to 6 GHz, making it suitable for a broad range of signal analysis applications.
• High Sampling Rate:
  • Provides sampling rates up to 5 GS/s, enabling the capture of fast and transient signals with high precision.
• High Dynamic Range:
  • Offers excellent dynamic range with a low DANL, allowing for accurate analysis of weak signals in the presence of strong signals.
• Resolution Bandwidth (RBW):
  • Selectable RBW from 1 Hz to 40 MHz provides flexibility for analyzing signals with different bandwidth requirements.
• Deep Memory:
  • Up to 512 MB of memory supports extensive data capture and detailed signal analysis over extended periods.
• Advanced Triggering:
  • Includes sophisticated triggering options to isolate specific signal events, aiding in precise data capture and analysis.
• Versatile Input Coupling:
  • AC coupling is available for a wide range of signal types and measurement needs.
• Software Integration:
  • Fully compatible with NI LabVIEW and other National Instruments software platforms, enabling efficient programming, control, and data analysis.

Application Scenarios

• RF and Microwave Signal Analysis:
  • Ideal for analyzing RF and microwave signals up to 6 GHz in applications such as communications, radar, and electronic warfare.
• Signal Integrity Testing:
  • Suitable for testing and ensuring the integrity of high-speed signal transmissions in electronic systems.
• Automated Test Systems:
  • Can be integrated into automated test systems for production testing and quality assurance where high-speed and accurate signal analysis is crucial.
• Research and Development:
  • Useful in R&D environments for analyzing complex signals, validating designs, and developing new technologies.
• Spectrum Analysis:
  • Provides high-performance spectrum analysis for a wide range of signals, from narrowband to wideband.
• Debugging and Validation:
  • Helps in debugging and validating electronic designs by capturing and analyzing signal anomalies and transient events.
