Technical Specifications:

• Chassis Type:
  • Form Factor: PXIe (PXI Express)
• Slots:
  • Number of Slots: 18
  • Slot Types:
    • 14 PXIe slots
    • 4 PXI slots
  • Backplane: Supports both PXIe and PXI modules, allowing for versatile system configurations and module integration.
• Power Supply:
  • Type: Internal power supply
  • Voltage: Provides all necessary power rails for PXIe modules
  • Cooling: Includes internal cooling fans for efficient ventilation and thermal management.
• Cooling:
  • Type: Internal fan cooling system designed for optimal airflow and effective heat dissipation.
• Operating Temperature:
  • Temperature Range: 0°C to 55°C (32°F to 131°F)
• Storage Temperature:
  • Storage Range: -40°C to 70°C (-40°F to 158°F)
• Relative Humidity:
  • Humidity Range: 10% to 90% non-condensing
• Dimensions:
  • Size: 6U height, suitable for both bench-top and rack-mounted configurations.
• Weight:
  • Weight: Approximately 18 kg (39.7 lbs)

Functional Features:

• High-Speed Data Transfer: Supports high-speed PXIe data transfer rates, making it ideal for applications requiring rapid data acquisition and processing.
• Versatile Slot Configuration: Offers a combination of PXIe and PXI slots, enabling flexible integration of various modules to accommodate different test and measurement needs.
• Compact and Durable Design: The 6U form factor provides a compact yet rugged design, suitable for both laboratory and field environments.
• Advanced Cooling System: Equipped with an internal cooling system to maintain optimal operating temperatures and ensure the reliability of connected modules.
• Power Management: Features an internal power supply with built-in protection, providing stable and reliable power to all connected modules.

Application Scenarios:

• Automated Test Systems: Ideal for high-performance automated test systems used in industries such as electronics, telecommunications, automotive, aerospace, and defense.
• Research and Development: Suitable for R&D environments where high-speed and high-throughput data acquisition and processing are essential.
• Production Test: Well-suited for production test environments that require reliable, efficient, and scalable testing solutions.
• Complex Test Systems: The high slot count and versatile configuration make it suitable for building complex and scalable test systems that demand high density and flexibility.

Additional Considerations:

• Driver and Software Support: Fully compatible with National Instruments’ software and drivers, including NI LabVIEW and NI MAX, for easy integration and configuration of PXIe modules.
• Integration and Expansion: Facilitates the integration of a wide range of PXIe and PXI modules, offering a scalable and adaptable platform for advanced test and measurement systems.
