Technical Specifications:

• Chassis Type:
  • Form Factor: PXIe (PXI Express)
• Slots:
  • Number of Slots: 18
  • Slot Types:
    • 14 PXIe slots
    • 4 PXI slots
  • Backplane: Supports both PXIe and PXI modules, allowing for flexible system configurations and integration of various modules.
• Power Supply:
  • Type: Internal power supply
  • Voltage: Provides all necessary power rails for PXIe modules
  • Cooling: Equipped with internal cooling fans to ensure proper ventilation and thermal management
• Cooling:
  • Type: Internal fan cooling system with optimized airflow for efficient heat dissipation.
• Operating Temperature:
  • Temperature Range: 0°C to 55°C (32°F to 131°F)
• Storage Temperature:
  • Storage Range: -40°C to 70°C (-40°F to 158°F)
• Relative Humidity:
  • Humidity Range: 10% to 90% non-condensing
• Dimensions:
  • Size: 6U height, compact design suitable for both bench-top and rack-mounted configurations.
• Weight:
  • Weight: Approximately 18 kg (39.7 lbs)

Functional Features:

• High-Speed Data Transfer: Supports high-speed PXIe data transfer rates, suitable for applications requiring rapid data acquisition and processing.
• Versatile Slot Configuration: Offers a mix of PXIe and PXI slots, providing flexibility for integrating a wide range of modules and adapting to different test and measurement requirements.
• Compact and Rugged Design: The 6U form factor allows for efficient use of space while ensuring durability and reliability in various environments.
• Built-In Cooling: Includes a robust cooling system to maintain optimal operating temperatures and ensure system stability.
• Power Management: Features an internal power supply with built-in protection to provide stable and reliable power to all connected modules.

Application Scenarios:

• Automated Test Systems: Ideal for high-performance automated test systems used in industries such as electronics, telecommunications, automotive, aerospace, and defense.
• Research and Development: Suitable for R&D environments where high-speed and high-throughput data acquisition and processing are critical.
• Production Test: Well-suited for production test applications where reliability, performance, and efficiency are essential.
• Complex Test Systems: Its high slot count and versatile configuration make it suitable for building complex and scalable test systems.

Additional Considerations:

• Driver and Software Support: Compatible with National Instruments’ software and drivers, including NI LabVIEW and NI MAX, for easy integration and configuration of PXIe modules.
• Integration and Expansion: Facilitates integration with a wide range of PXIe and PXI modules, offering a scalable and flexible platform for building sophisticated test systems.
