Technical Specifications:

• Switch Type: Matrix Switch
• Form Factor: PXI (PCI eXtensions for Instrumentation)
• Channel Count: 64 x 64 (cross-point matrix switch)
• Switch Type: Electromechanical
• Maximum Switching Voltage: 30 V
• Maximum Switching Current: 1 A
• Maximum Switching Power: 30 W
• Contact Resistance: < 0.1 Ω
• Insulation Resistance: > 10^9 Ω
• Operating Temperature: 0°C to 55°C
• Storage Temperature: -40°C to 70°C
• Relative Humidity: 10% to 90% non-condensing

Functional Features:

• High-Density Matrix Switching: Provides a 64 x 64 matrix configuration, enabling extensive and flexible signal routing within a single module.
• High-Current Capability: Handles up to 1 A per channel, suitable for various high-current applications.
• Low Contact Resistance: Ensures minimal signal loss and high measurement accuracy, which is critical for precision testing.
• Electromechanical Relays: Utilizes electromechanical relays for reliable and durable performance.
• High Power Handling: Capable of managing up to 30 W of power, accommodating a broad range of test and measurement needs.

Application Scenarios:

• Automated Test Systems: Ideal for use in automated test setups that require high-density and flexible switching solutions for managing multiple signals and connections.
• System Simulation: Useful for simulating various circuit configurations and system states during research, development, and testing phases.
• Signal Routing: Facilitates efficient routing of signals between multiple components or instruments, enhancing the flexibility and capability of test setups.
• Measurement and Control: Supports advanced measurement and control applications by managing and switching numerous test signals.

Additional Considerations:

• Driver and Software Support: Requires National Instruments’ drivers and software, such as NI LabVIEW or NI TestStand, for configuration and control. Ensure compatibility with your PXI system’s software environment.
• Integration and Configuration: Integrated with National Instruments’ software tools, offering ease of setup and operation for complex testing and measurement scenarios.
