Technical Specifications:

• Switch Type: Matrix Switch
• Form Factor: PXI (PCI eXtensions for Instrumentation)
• Channel Count: 64 x 64 (cross-point matrix switch)
• Switch Type: Electromechanical
• Maximum Switching Voltage: 30 V
• Maximum Switching Current: 2 A
• Maximum Switching Power: 60 W
• Contact Resistance: < 0.1 Ω
• Insulation Resistance: > 10^9 Ω
• Operating Temperature: 0°C to 55°C
• Storage Temperature: -40°C to 70°C
• Relative Humidity: 10% to 90% non-condensing

Functional Features:

• High-Density Matrix Switching: Provides a 64 x 64 matrix configuration, enabling extensive and flexible signal routing within a single module.
• High-Current Capability: Supports up to 2 A per channel, making it suitable for high-current applications.
• Low Contact Resistance: Ensures minimal signal loss and high measurement accuracy, crucial for precision testing.
• Electromechanical Relays: Utilizes reliable electromechanical relays for robust performance in switching tasks.
• High Power Handling: Capable of managing up to 60 W of power, versatile for various testing and measurement scenarios.

Application Scenarios:

• Automated Test Systems: Ideal for use in automated testing environments where high-density and flexible switching are needed to manage multiple signals and connections.
• System Simulation: Useful for simulating different circuit configurations and system states during research and development.
• Signal Routing: Facilitates efficient routing of signals between multiple components or instruments, enhancing the capability of test setups.
• Measurement and Control: Assists in managing and switching numerous test signals, supporting complex measurement and control applications.

Additional Considerations:

• Driver and Software Support: Requires appropriate drivers and software from National Instruments, such as NI LabVIEW or NI TestStand, for configuration and control. Ensure compatibility with your PXI system’s software environment.
• Integration and Configuration: Easily integrated into National Instruments’ software ecosystems, providing flexibility and ease of use for complex testing needs.
