Technical Specifications:

• Switch Type: Matrix Switch
• Form Factor: PXI (PCI eXtensions for Instrumentation)
• Channel Count: 64 x 64 (cross-point matrix switch)
• Switch Type: Electromechanical
• Maximum Switching Voltage: 30 V
• Maximum Switching Current: 1 A
• Maximum Switching Power: 30 W
• Contact Resistance: < 0.1 Ω
• Insulation Resistance: > 10^9 Ω
• Operating Temperature: 0°C to 55°C
• Storage Temperature: -40°C to 70°C
• Relative Humidity: 10% to 90% non-condensing

Functional Features:

• High-Density Matrix Switching: Provides a 64 x 64 matrix configuration, enabling extensive signal routing capabilities within a single module.
• Flexible Switching: Supports complex switching tasks with high-density configurations, useful for a variety of testing and measurement applications.
• High-Current Capability: Handles switching currents up to 1 A per channel, suitable for a range of high-current applications.
• Low Contact Resistance: Ensures minimal signal loss and high measurement accuracy, which is crucial for precision tests.
• Electromechanical Relays: Uses reliable electromechanical relays for dependable performance in signal switching tasks.
• High Power Handling: Capable of managing up to 30 W of power, making it versatile for different test and measurement scenarios.

Application Scenarios:

• Automated Test Systems: Ideal for automated test environments where high-density and flexible signal routing are required for managing multiple signals and connections.
• System Simulation: Useful for creating and managing various circuit configurations and system states during development and testing.
• Signal Routing: Facilitates efficient routing of signals between multiple components or instruments, enhancing test setup capabilities.
• Measurement and Control: Assists in managing and switching numerous test signals, supporting advanced measurement and control applications.

Additional Considerations:

• Driver and Software Support: Requires National Instruments’ drivers and software, such as NI LabVIEW or NI TestStand, for configuration and control. Ensure compatibility with your PXI system’s software environment.
• Integration and Configuration: Integrated with National Instruments’ software tools, allowing for effective setup and operation in complex testing scenarios.
