  3. NI PXI-2523

NI PXI-2523

The NI PXI-2523 is a PXI switching module from National Instruments designed to offer high-density and flexible switching solutions.

WhatApp
WeChat

Detailed content

Technical Specifications:

  • Switch Type: Matrix Switch
  • Form Factor: PXI (PCI eXtensions for Instrumentation)
  • Channel Count: 64 x 64 (cross-point matrix switch)
  • Switch Type: Electromechanical
  • Maximum Switching Voltage: 30 V
  • Maximum Switching Current: 1 A
  • Maximum Switching Power: 30 W
  • Contact Resistance: < 0.1 Ω
  • Insulation Resistance: > 10^9 Ω
  • Operating Temperature: 0°C to 55°C
  • Storage Temperature: -40°C to 70°C
  • Relative Humidity: 10% to 90% non-condensing

Functional Features:

  • High-Density Matrix Switching: Provides a 64 x 64 matrix configuration, allowing for extensive and complex signal routing and management within a single module.
  • High-Current Capability: Handles switching currents up to 1 A per channel, making it suitable for various high-current applications.
  • Low Contact Resistance: Offers minimal signal loss and high measurement accuracy, crucial for precise testing and measurement tasks.
  • Electromechanical Relays: Uses electromechanical relays for reliable switching, supporting a range of signal routing and switching needs.
  • High Power Handling: Capable of managing up to 30 W of power, accommodating different test and measurement scenarios.

Application Scenarios:

  • Automated Test Systems: Perfect for use in automated test environments where high-density and flexible signal routing is needed.
  • System Simulation: Useful for simulating different circuit configurations and system states during research and development.
  • Signal Routing: Efficiently routes signals between multiple components or instruments in a test setup.
  • Measurement and Control: Facilitates the management and switching of numerous test signals, enhancing measurement and control applications.

Additional Considerations:

  • Driver and Software Support: Requires appropriate drivers and software from National Instruments, such as NI LabVIEW or NI TestStand, for configuration and control. Ensure compatibility with your PXI system and software environment.
  • Configuration and Integration: Easily integrated into National Instruments’ software ecosystems for effective setup and operation.
