Technical Specifications:

• Switch Type: Matrix Switch
• Form Factor: PXI (PCI eXtensions for Instrumentation)
• Channel Count: 64 x 64 (cross-point matrix switch)
• Switch Type: Electromechanical (for high-current switching)
• Maximum Switching Voltage: 30 V
• Maximum Switching Current: 2 A
• Maximum Switching Power: 60 W
• Contact Resistance: < 0.1 Ω
• Insulation Resistance: > 10^9 Ω
• Operating Temperature: 0°C to 55°C
• Storage Temperature: -40°C to 70°C
• Relative Humidity: 10% to 90% non-condensing

Functional Features:

• High-Density Matrix Switching: Offers a 64 x 64 matrix configuration, which allows for extensive signal routing and management within a single module.
• High Current Handling: Capable of handling up to 2 A per channel, making it suitable for applications involving higher current signals.
• Low Contact Resistance: Ensures minimal signal loss and high measurement accuracy, crucial for precise testing applications.
• Electromechanical Relays: Utilizes electromechanical relays for reliable switching, suitable for both low and high-power applications.
• High Power Handling: Handles up to 60 W of power, accommodating a wide range of test and measurement scenarios.

Application Scenarios:

• Automated Test Systems: Ideal for automated test setups requiring complex signal routing and high-density switching capabilities.
• System Simulation: Used for simulating various circuit configurations and system states, aiding in development and troubleshooting.
• Signal Routing: Efficiently routes signals between different components or instruments, supporting various testing and measurement needs.
• Measurement and Control: Facilitates the management and switching of multiple test signals in measurement and control applications.

Additional Considerations:

• Driver and Software Support: Requires National Instruments’ drivers and software, such as NI LabVIEW or NI TestStand, for configuration and control. Ensure compatibility with your PXI system’s software.
• Configuration and Control: Easily integrated into National Instruments’ software environments, providing flexibility and ease of use for complex test setups.
