Technical Specifications:

• Switch Type: Matrix Switch
• Form Factor: PXI (PCI eXtensions for Instrumentation)
• Channel Count: 64 x 64 (cross-point matrix switch)
• Switch Type: Electromechanical (for high-current switching)
• Maximum Switching Voltage: 30 V
• Maximum Switching Current: 1 A
• Maximum Switching Power: 30 W
• Contact Resistance: < 0.1 Ω
• Insulation Resistance: > 10^9 Ω
• Operating Temperature: 0°C to 55°C
• Storage Temperature: -40°C to 70°C
• Relative Humidity: 10% to 90% non-condensing

Functional Features:

• High-Density Matrix Switching: Provides 64 x 64 matrix switching, enabling the routing of multiple signals with a single module.
• Flexible Configuration: Supports a wide range of switching tasks, including signal routing and system simulation.
• Low Contact Resistance: Ensures minimal signal loss and high measurement accuracy.
• Electromechanical Relays: Offers reliable switching for a variety of applications with a maximum switching current of 1 A.
• High Power Handling: Capable of handling up to 30 W of power, suitable for high-power applications.

Application Scenarios:

• Automated Test Systems: Ideal for use in automated test environments where complex signal routing and high-density switching are required.
• System Simulation: Useful for simulating different circuit configurations and system states during R&D.
• Signal Routing: Facilitates efficient routing of signals between different instruments or components in a test setup.
• Measurement and Control: Employed in measurement systems to manage multiple test signals and control various aspects of the test environment.

Additional Considerations:

• Driver and Software Support: Requires appropriate drivers and software, such as NI LabVIEW or NI TestStand, for configuration and control. Ensure compatibility with the PXI system’s software environment.
• Configuration and Control: Easily integrated with National Instruments’ software tools for setup and operation.
