Technical Specifications:

• Switch Type: Matrix Switch
• Form Factor: PXI (PCI eXtensions for Instrumentation)
• Channel Count: 64 x 64 (cross-point matrix switch)
• Switch Type: Electromechanical (for high-current switching)
• Maximum Switching Voltage: 30 V
• Maximum Switching Current: 2 A
• Maximum Switching Power: 60 W
• Contact Resistance: < 0.1 Ω
• Insulation Resistance: > 10^9 Ω
• Operating Temperature: 0°C to 55°C
• Storage Temperature: -40°C to 70°C
• Relative Humidity: 10% to 90% non-condensing

Functional Features:

• High-Density Switching: Provides 64 x 64 matrix switching, allowing for complex signal routing and management.
• Flexible Configuration: Can be used for a variety of switching tasks, including signal routing, automated testing, and system simulation.
• High Current Capability: Capable of handling high-current switching applications with a maximum of 2 A per channel.
• Low Contact Resistance: Ensures minimal signal loss and high accuracy in measurements.
• Electromechanical Relays: Offers reliable switching with low contact resistance, suitable for high-current and high-power applications.

Application Scenarios:

• Automated Test Systems: Ideal for use in automated test setups where complex signal routing and high-density switching are required.
• System Simulation: Can be used to simulate various circuit configurations and system states in research and development.
• Signal Routing: Useful for routing signals between different components or instruments in a test system.
• Measurement and Control: Employed in measurement systems to manage and switch multiple test signals efficiently.

Additional Considerations:

• Driver and Software Support: Compatible with National Instruments’ software and drivers for integration with PXI systems. Ensure the use of appropriate drivers for configuration and control.
• Configuration and Control: Controlled via NI’s software tools, such as NI TestStand or LabVIEW, allowing for easy integration and programming in test setups.
