Technical Specifications:

• Interface: PCI Express (PCIe) x4
• Form Factor: Standard PCIe card
• Connector: Used to interface with PXI or PXIe chassis
• Data Transfer Rate: Up to 2 GB/s (bidirectional)
• Operating Temperature: 0°C to 55°C
• Storage Temperature: -40°C to 85°C
• Relative Humidity: 10% to 90% non-condensing

Functional Features:

• High-Speed Data Transfer: Supports high-speed data communication between the PC and PXI/PXIe systems, essential for applications requiring fast data acquisition and processing.
• PXI/PXIe Chassis Connectivity: Enables communication between the host computer and PXI/PXIe modules, facilitating the integration of multiple instruments and modules within a test system.
• Auto-Recognition: Automatically detects and configures PXI/PXIe modules, simplifying system setup and reducing configuration time.
• PCIe x4 Interface: Provides a high-bandwidth connection, ensuring reliable and efficient data transfer.

Application Scenarios:

• Automated Test Systems: Ideal for use in automated test environments where fast and reliable data transfer between the PC and PXI/PXIe modules is crucial.
• Data Acquisition: Suitable for applications requiring high-speed data acquisition from PXI/PXIe instrumentation.
• Signal Processing: Used in systems that involve complex signal processing tasks, where high data throughput is necessary.
• Measurement and Control: Employed in measurement and control systems where precise and rapid communication between different hardware components is needed.

Additional Considerations:

• Compatibility: Ensure compatibility with the specific PXI/PXIe chassis and modules being used, as well as with the operating system and software environment.
• Driver and Software Support: Requires appropriate drivers and software (such as NI software and drivers) for proper operation and integration with other National Instruments hardware and software tools.
