NI ARINC-429

The NI ARINC-429 is a National Instruments module designed for interfacing with ARINC 429 data buses, commonly used in avionics and aerospace applications.

WhatApp
WeChat

Detailed content

1. Technical Specifications

  • Model: NI ARINC-429
  • Type: ARINC 429 Interface Module
  • Bus Type: ARINC 429
  • Number of Channels:
    • Transmit Channels: Typically up to 4
    • Receive Channels: Typically up to 4
  • Data Rate: Supports data rates of 12.5 kbps and 100 kbps, conforming to ARINC 429 standards.
  • Connector Type: Typically uses D-sub or similar connectors for physical interface.
  • Power Supply: Operates with a standard PCIe or PXI power supply, depending on the specific module form factor.

2. Key Features

  • ARINC 429 Compliance: Fully compliant with the ARINC 429 standard, which is widely used in aircraft avionics for data communication.
  • Data Transmission and Reception: Capable of both transmitting and receiving ARINC 429 data, with multiple channels for flexibility.
  • Software Support: Compatible with National Instruments’ LabVIEW and other software for easy integration into data acquisition and control systems.
  • High Accuracy and Reliability: Designed for high precision and reliability in critical aerospace applications.

3. Application Scenarios

  • Avionics Systems: Utilized in aircraft avionics systems for interfacing with various avionic equipment that uses ARINC 429 for communication.
  • Aerospace Testing: Employed in aerospace test setups for simulating and analyzing ARINC 429 data traffic.
  • Flight Data Recorders: Used in flight data acquisition and recording systems where ARINC 429 is the communication protocol.
  • Simulation and Training: Applied in simulation systems for training and development purposes where ARINC 429 data communication is required.

4. Additional Information

  • Integration: The NI ARINC-429 module is typically integrated into National Instruments’ data acquisition systems such as PXI or PCIe platforms.
  • Software Tools: Comes with software tools and libraries for easy setup and configuration, often including support for LabVIEW.
  • Technical Support: For detailed specifications, installation instructions, and technical support, consult the official datasheet or contact National Instruments.
