Technical Specifications:

• Power Supply Input: 9 V to 30 V DC
• Continuous Current Output: Up to 5 A
• Peak Current Output: 10 A (for brief periods)
• PWM Frequency: 20 kHz
• Control Modes: Open-loop (voltage control), closed-loop (current control), and closed-loop (position control) when integrated with appropriate feedback devices.
• Feedback Options: Supports encoder feedback for closed-loop control.

Features:

• CompactRIO Compatibility: Integrates seamlessly with CompactRIO systems, offering high flexibility in control and monitoring tasks.
• High Current Drive: Capable of driving high-current motors, making it suitable for demanding industrial applications.
• Integrated Safety Features: Includes features like overcurrent protection, thermal shutdown, and configurable brake options to ensure safe operation.
• Encoder Support: Allows precise position and speed control by using encoder feedback, essential for applications requiring high accuracy.
• Software Integration: Compatible with LabVIEW, allowing for easy programming and integration into complex control systems.

Application Scenarios:

• Robotics: Ideal for controlling motors in robotic arms, mobile robots, and other robotic systems where precise motor control is crucial.
• Automation: Used in automated machinery for tasks that require precise motor control, such as conveyor systems, automated guided vehicles (AGVs), and CNC machines.
• Test and Measurement: Useful in test rigs where motors are used to simulate real-world conditions or to perform endurance testing of mechanical components.
