Data Acquisition Channels:16

Analog Input Range:±10 V

Digital I/O Lines:16

Sampling Rate:20 MS/s

Power Supply:5V DC

Dimensions (WxHxD):2.3 x 4.4 x 17.6 inches

Weight:6.5 lbs

Operating Temperature:-20°C to +60°C

Operating Humidity:5% to 95% non-condensing

Connectors:USB 3.0, RS-232, Ethernet

Operating System Compatibility:Windows, Linux, macOS

    The PXI-8105 is a highly integrated modular instrument that combines precision, reliability, and efficiency in a compact form factor, making it an ideal choice for a wide range of applications requiring high-speed data acquisition and control.

    Featuring a robust design with high-speed data transfer capabilities via USB 3.0 or Ethernet, this instrument ensures seamless integration into modern test systems and industrial control environments.

    Equipped with 16 high-resolution analog input channels and 128 digital I/O lines, the PXI-8105 provides the flexibility and versatility needed to handle complex data acquisition tasks, from sensor monitoring to signal conditioning and beyond.

    Designed with ease of use in mind, the PXI-8105 supports National Instruments’ industry-leading DAQmx software, allowing users to quickly develop and deploy test and measurement applications.

    Built to withstand challenging industrial conditions, the PXI-8105 operates within a wide temperature range (-10°C to 55°C), ensuring reliable performance in various environments, from laboratory settings to rugged field conditions.
