1. Technical Specifications

• Model: Motorola V-816398
• Type: VMEbus Single-Board Computer
• Processor:
  • Type: Generally equipped with a Motorola 680×0 series or PowerPC processor.
  • Clock Speed: Processor speeds can vary, typically from 25 MHz to 400 MHz, depending on the specific configuration.
• Memory:
  • RAM: Typically offers between 4 MB to 64 MB of onboard RAM.
  • Flash Memory: Flash storage usually ranges from 2 MB to 16 MB for storing firmware and application data.
• I/O Interfaces:
  • Serial Ports: Includes multiple serial ports (RS-232 and/or RS-422) for external communication.
  • Parallel I/O: Features general-purpose parallel I/O ports for additional peripheral connectivity.
  • Ethernet: Provides Ethernet connectivity (10/100Base-T) for network integration.
  • SCSI: Some configurations include SCSI interfaces for connecting high-speed storage devices.
  • PCI: Certain models may offer PCI slots for expansion and additional hardware integration.
• Bus Interface:
  • VMEbus: Compliant with VMEbus standards for integration with other VMEbus systems and modules.
• Power Requirements:
  • Power Consumption: Designed to adhere to VMEbus power specifications. Exact power requirements should be confirmed in the datasheet.

2. Key Features

• Processor Options: Provides flexibility with different processors including the Motorola 680×0 series and PowerPC, catering to various performance needs.
• Memory Expansion: Configurable RAM and flash memory to accommodate a range of applications and data storage requirements.
• Extensive I/O Capabilities: Equipped with multiple interfaces such as serial ports, parallel I/O, Ethernet, and potentially SCSI, enabling comprehensive connectivity.
• VMEbus Compliance: Ensures compatibility and integration with other VMEbus-based systems, facilitating system expansion and interoperability.

3. Application Scenarios

• Industrial Automation: Ideal for use in industrial control systems that require robust processing power and extensive I/O capabilities.
• Embedded Systems: Suitable for embedded applications needing reliable VMEbus integration and high-performance processing.
• Defense and Aerospace: Utilized in defense and aerospace applications where VMEbus compatibility and rugged performance are critical.
• Telecommunications: Applied in telecommunications systems requiring dependable network connectivity and high-speed data handling.

4. Additional Information

• Installation and Maintenance: The V-816398 is designed to be installed in a VMEbus chassis. Proper installation, configuration, and ongoing maintenance are essential for optimal operation.
• Technical Support: For the most accurate and comprehensive details, including technical specifications, installation guidelines, and support, refer to the official datasheet or contact Motorola (now part of Analog Devices) or their authorized distributors.
