Motorola MVME761-001
The Motorola MVME761-001 is a versatile transition module primarily designed for VMEbus-based systems, serving as a bridge between standard industry interfaces and high-performance backplane systems. This module simplifies the connection of Ethernet, serial, and parallel port signals, making it easier to integrate into industrial automation systems.
Detailed content
Key Features:
- Industry Standard Interfaces:
- Two EIA-574 asynchronous serial ports (DTE)
- Two asynchronous/synchronous serial ports configurable for various interfaces like EIA-232-D, EIA-530, V.35, or X.21
- IEEE 1284-compliant parallel port
- 10Base-T/100Base-TX Ethernet
- SIM Connectors:
- Two 60-pin Serial Interface Module (SIM) connectors to configure the serial ports.
- Robust Build:
- The module comes with Electro-Magnetic Interference (EMI) and Electro-Static Discharge (ESD) protection.
- Designed to operate in forced-air environments with temperatures ranging from 0°C to 55°C.
- Cooling Requirements:
- Requires airflow of 5 cubic feet per minute for optimal cooling, depending on ambient temperature and module configuration.
- Compliance:
- Meets FCC Class A emissions standards when installed correctly with shielded cables and grounded chassis rails.
Applications:
The MVME761-001 is suitable for use in industrial automation, telecommunications, and energy sectors, where high-performance control and data acquisition are needed. It is especially useful for integrating legacy systems with newer network protocols in environments that demand real-time data processing.
