1. Technical Specifications

• Model: Motorola MVME-717
• Type: VMEbus Single-Board Computer
• Processor:
  • Type: Uses a Motorola 68040 microprocessor.
  • Clock Speed: Operates at 25 MHz or 33 MHz, depending on the configuration.
• Memory:
  • RAM: Typically comes with onboard RAM options ranging from 4 MB to 16 MB.
  • ROM/Flash: Includes ROM for firmware storage; some configurations may support flash memory for easier updates.
• I/O Interfaces:
  • Serial Ports: Features multiple serial ports, such as RS-232 and RS-422, for serial communication.
  • Parallel I/O: Provides general-purpose parallel I/O ports for interfacing with external devices.
  • Ethernet: Equipped with Ethernet interfaces, usually supporting 10Base-T or 100Base-TX for network connectivity.
  • Additional Interfaces: May include SCSI or IDE interfaces depending on the specific configuration.
• Bus Interface:
  • VMEbus: Compliant with VMEbus standards, enabling integration with VMEbus systems and other modules.
• Power Requirements:
  • Operates within standard VMEbus power specifications. Exact power consumption and voltage requirements should be confirmed from the datasheet.

2. Key Features

• VMEbus Compliance: Fully adheres to VMEbus standards, ensuring compatibility with other VMEbus-based systems.
• High Performance: Utilizes the Motorola 68040 processor, which offers robust performance for demanding applications.
• Versatile I/O Options: Includes a variety of I/O interfaces, allowing for flexible connectivity and integration with other peripherals.
• Memory Expandability: Supports additional memory for scaling up according to application needs.
• Networking Capabilities: Ethernet interfaces provide essential network connectivity for integrated systems.

3. Application Scenarios

• Industrial Automation: Ideal for use in industrial control systems where reliable and high-performance computing is necessary for managing and controlling processes and machinery.
• Defense and Aerospace: Suitable for defense and aerospace applications due to its ruggedness and high computational power.
• Medical Systems: Applied in medical diagnostic and imaging systems where performance and reliability are critical.
• Embedded Systems: Used in embedded systems requiring VMEbus compatibility and substantial processing power for various applications.

4. Additional Information

• Installation and Maintenance: The MVME-717 is designed to be installed into a VMEbus chassis. Proper configuration and regular maintenance are required to ensure it operates optimally.
• Technical Support: For detailed technical specifications, installation procedures, and troubleshooting, refer to the official product datasheet or contact Motorola or its authorized distributors for support.
